| Item | Centrifugal Pump |
| Best Efficiency Head | 90 ft. to 120 ft. |
| Compatible Discharge Pipe Size | 2 1/2" |
| Compatible Intake Pipe Size | 3" |
| Connection Type | NPT |
| Duty Cycle | Continuous |
| For Use With Potable Systems | No |
| Frequency | 60 Hz |
| Height | 13 1/5" |
| Housing Material | Cast Iron |
| Hp | 5 hp |
| Impeller Material | Silicon Bronze |
| Length | 23" |
| Max. Flow Rate | 218 GPM |
| Max. Flow Rate @ 10 Ft. | 211 GPM |
| Max. Flow Rate @ 20 Ft. | 167 GPM |
| Max. Flow Rate @ 5 Ft. | 218 GPM |
| Max. Head | 115.5 ft. |
| Max. Rpm | 3500 RPM |
| Max. Solid Dia. | 0.13" |
| Media Type | Water |
| Min. Flow Rate | 65 GPM |
| Min. Head | 46.2 ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Outlet Type | NPT |
| Phase | 3 |
| Pumping Application | Dewatering, Lawn Irrigation, Liquid Transfer, Live Stock Watering, Plot Irrigation |
| Seal Material | Stainless Steel, Buna N, Carbon Ceramic |
| Seal Material Grade | Grade 316 |
| Self Priming | Yes |
| Series | SP Series |
| Voltage | 208-230/460V AC |
| Wetted Material | Bronze, Buna N, Carbon Ceramic, Stainless Steel |
| Wetted Material Grade | Grade 316 |
| Width | 11 2/5" |
| Compatible With Media Type | Water |
| Discharge Type | NPT |
| Feet Of Head (minimum) | 46.2 ft. |
| Flow Rate (maximum) | 218 GPM |
| Flow Rate (minimum) | 65 GPM |
| Horsepower | 5 hp |
| Maximum Feet Of Head | 115.5 ft. |
| Maximum Flow Rate @ 10 Feet Of Head | 211 GPM |
| Maximum Flow Rate @ 20 Feet Of Head | 167 GPM |
| Maximum Flow Rate @ 5 Feet Of Head | 218 GPM |
| Motor Enclosure | Totally Enclosed Fan Cooled |
| Nameplate Voltage | 208-230/460V AC |
| Overall Height | 13 1/5" |
| Overall Length | 23" |
| Overall Width | 11 2/5" |
| Priming | Self Priming |
| Pump Housing Material | Cast Iron |
| Rpm (maximum) | 3500 RPM |
| Solid Diameter (maximum) | 0.13" |
| Standards | ANSI 61, NSF CERTIFIED |
