| Item | Lock Lever |
| Ada Compliant | Yes |
| Backset | 2 3/4" |
| Cylinder Core Type | Not Included |
| Electrical/mechanical | Mechanical |
| Features | Cylindrical Locks |
| Finish | Oil Rubbed Bronze |
| For Use With | Various Door Types |
| Function | Passage |
| Handle Material | Zinc |
| Handle Type | Lever |
| Includes | Strike |
| Key Type | Not Keyed |
| Keyway Type | None |
| Ligature Resistant | No |
| Location Type | Commercial |
| Lockset Fire Rating | Not Rated |
| Lockset Performance Strength | Medium Duty |
| Mortise / Cylindrical | Cylindrical |
| Number Of Keys | 0 |
| Pins | 0 |
| Required Door Thickness | 1 3/8" to 2" |
| Strike Dim. | 1 1/4" x 4 7/8" |
| Strike Type | ASA Strike |
| Style | B Quantum |
| Visual Indicator Message | No Message |
| Ansi Grade | Grade 2 |
| Ansi Lockset Function | Passage |
| Bolt Type | Spring Latch |
| Door Thickness - Maximum | 2" |
| Door Thickness - Minimum | 1 3/8" |
| Fire Rating | 3 hrs. |
| General Lockset Function | Passage Lever Locksets |
| Hand Orientation | Non Handed |
| Includes Core | Core Not Included |
| Inside Locking Access | Not Lockable |
| Knob/handle Material | Bronze |
| Ligature Resistance | Not Ligature Resistant |
| Lock Assembly Type | Cylindrical |
| Lockset Function Ansi Code | F75 |
| Lockset Handle Type | Lever |
| Lockset Style | Quantum |
| Lockset Type | Mechanical |
| Mounting Style | Thru Bolt |
| Number Of Pins | 6 |
| Outside Locking Access | Not Lockable |
| Performance Duty Rating | 2 |
| Properties | Rust Resistant |
| Standards | ANSI/BHMA A156.2 |
| Strike Plate Height | 4 7/8" |
| Strike Plate Width | 1 1/4" |
| Ship weight (kg) | 1.62 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
B501PD D 626 | Lock | €282.63 | |
 |
B301S D 626 | Door Lever Lockset | €208.80 | |
 |
T561PD D 626 | Door Lever Lockset | €440.82 | |
 |
B511PD D 626 | Door Lever Lockset | €251.74 | |
 |
B561BD D 626 | Door Lever Lockset | €241.56 | |
 |
B561CP6D D 626 | Door Lever Lockset | €228.63 | |
 |
B511BD D 626 | Door Lever Lockset | €233.54 |
