ENERPAC ATM4 Flange Alignment Tool, 4 Ton
Get it by Tuesday, Jun 17
€6,503.31 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Flange Alignment Tool |
| Application | Lift, Lower |
| Flange Thickness | 1.18" to 5.23" |
| Force | 4 ton. |
| Includes | Kit Box |
| Max. Reaction Force | 4 ton. |
| Min. Bolt Dia. | 1" |
| Min. Bolt Size | 1" |
| Overall Width | 2 1/2" |
| Promotion Restriction | Not Eligible For Promotion |
| Features | Correct Flange Misalignment and Place Bolts, for Use with Most Ansi, Api, Bs and Din Flanges, Install and Use Vertically or Horizontally, No Slings, Hooks or Lifting Gear Required, Rectify Twist and Rotational Misalignment |
| Maximum Flange Capacity | 4 ton. |
| Maximum Flange Thickness | 5 1/4" |
| Minimum Bolt Diameter | 1" |
| Minimum Flange Thickness | 1 3/16" |
| Product Type | Mechanical Flange Alignment Tool |
| Spread | 6 3/8" |
| Tool Height | 11 1/2" |
| Tool Length | 18 15/16" |
| Tool Series | ATM |
| Tool Weight | 19 lbs. |
| Tool Width | 2 1/2" |
| Ship weight (kg) | 14.4 |
| Ship height (cm) | 19.99 |
| Ship length (cm) | 59 |
| Ship width (cm) | 69.01 |
| Country of Origin | UK |
