| Item | Gauge |
| Connection Type | Barbed |
| Mounting Orientation | Diaphragm In Vertical Position |
| Operating Temp. Range | +20°F to +120°F |
| Pressure Range | 0 in. wc to 3 in. wc |
| Accuracy | +/-5.00% |
| Ambient Operating Temperature Range | 20°F to 120°F |
| Application | Air Samplers, Cabinet Air-Purging, Duct Pressures, Electronic Air Cooling Systems, Face Velocity On Fume Hood, Laminar Flow Hoods, Local Indication On Filter Status, Room Positive Pressure Sensing |
| Case Diameter | 3.062" |
| Case Material | Nylon |
| Compatible Process Media | Air and Compatible Non-Corrosive Gases |
| For Panel Cut-out Size | 2 5/8" |
| Housing Material | Glass Filled Nylon |
| Includes Calibration Certificate | No |
| Includes Mounting Hardware | Yes |
| Lens Material | Polycarbonate |
| Mounting Type | Surface Mount |
| Nominal Dial Size | 2 1/16" |
| Panel Mount Characteristics | (2) #4-40 Screws Into Tapped Mounting Bracket Stud Holes" Rear of Gauge |
| Pointer Color | Red |
| Pressure Gauge Type | Differential Pressure Gauge |
| Process Connection Gender | Male |
| Process Connection Location | Back |
| Process Connection Size | 3/16" |
| Process Connection Type | Hose Barb |
| Sensor Material | Silicone Rubber |
| Sensor Type | Diaphragm |
| Series | 2-5000 Minihelic II |
| Standards | EU ROHS II |
| Ship weight (kg) | 0.45 |
| Ship height (cm) | 5.91 |
| Ship length (cm) | 5.91 |
| Ship width (cm) | 6.03 |
| Country of Origin | US |
| Model | Connection Type | Item | Pressure Range | Price | |
|---|---|---|---|---|---|
| 2-5210 | Barbed | Differential Pressure Gauge | 0 psi to 10 psi | €112.73 | |
| 2-5003-NPT | Npt | Gage | 0 in. wc to 3 in. wc | €106.47 | |
| 2-5010 | Barbed | Gauge | 0 in. wc to 10 in. wc | €112.87 | |
| 2-5020 | Barbed | Gauge | 0 in. wc to 20 in. wc | €115.17 | |
| 2-5000-0 | Barbed | Gauge | 0 in. wc to 0.5 in. wc | €106.44 | |
| 2-5001 | Barbed | Pressure Gauge | 0 in. wc to 1 in. wc | €112.87 | |
| 2-5005 | Barbed | Gauge | 0 in. wc to 5 in. wc | €112.87 |
