| 75% Thread Drill Size | C |
| Features | Thread Cutting |
| Flute Type | Straight |
| Interrupted Thread | No |
| Max. Projection | 0.312" |
| Measurement System | Decimal Inch |
| Number Of Flutes | 4 |
| Overall Length | 2.125" |
| Primary Material Application | Cast Iron, Non-Ferrous (Aluminum), Steel |
| Primary Material Application Iso Code | K, N, P |
| Shank Dia. | 0.3125" |
| Shank Length | 0.3750" |
| Shank Type - Machining | Straight |
| Spiral Direction | Right Hand |
| Square Size | 0.3750" |
| Tap Chamfer | Semi Bottoming |
| Tap Finish | Bright |
| Tap Length Standard | USCTI |
| Tap Material | High Speed Steel |
| Tap Shank Standard | USCTI |
| Tap Style | Pipe Tap |
| Thread Direction | Right Hand |
| Thread Length | 0.7000" |
| Thread Size | 1/16"-27 |
| Thread Standard | NPT |
| Threads Per Inch | 27 |
| Ship weight (kg) | 0.01 |
| Ship length (cm) | 5.4 |
| Country of Origin | US |
