BROWNING E462 6GWBPF1 85.5 Worm Helical Reducer, Right Angle, Double Reduction
€2,060.67 /unit
Request a Quote
Payment
Payment
| Item | Reducer |
| Base Included | Yes |
| Base To Center Of Input Shaft | 5 7/8" |
| Base To Center Of Output Shaft | 6.313" |
| Bolt Hole Dia. | 0.563" |
| Center Distance | 0.438" |
| Fan Cooled | No |
| Gear Type | Helical Worm |
| Height | 9.69" |
| Housing Material | Cast Iron |
| Input Rating Value Plus Um | 1 hp |
| Input Style | C Face Quill |
| Max. Nominal Input Rating | 1 hp |
| Max. Overhung Load Value And Um | 1228 lbs. |
| Motor Included | No |
| Mounting Bolt Pattern Footprint | Rectangular |
| Mounting Frame | 145T |
| Mounting Method | Direct Mounted |
| Mounting Position | Floor |
| Nominal Ratio | 85.5:1 |
| Output Rpm | 20 RPM |
| Output Shaft Dia. | 1 1/2" |
| Output Shaft Length | 3" |
| Output Type | Right Hand |
| Overall Length | 12.81" |
| Overall Width | 13.344" |
| Product Series | GWB Series |
| Reducer Type | Right Angle |
| System Of Measurement | Imperial |
| Torque Rating | 2365 lbs.-in. |
| Weight | 26.782 Kg |
| Ship weight (kg) | 27.9 |
