BROWNING 1020890 4MVP85C107Q V-Belt Sheave, Multiple, Variable Pitch, Bushed Bore, 4 Groove, Cast Iron
Get it by Monday, Jun 16
€3,717.49 /unit
Add To Cart
Request a Quote
Payment
Get it by Monday, Jun 16
Payment
| Item | V-Belt Sheave |
| Adjustment Method | Manual Turn |
| Belt Series | C Series |
| Bore Dia. | 1 3/8" |
| Bore Type | Split Taper |
| Bushing Bore Range | 1 3/8" to 2 1/2" |
| Bushing Type | Q3 |
| Face Width | 6 3/32" to 6 11/16" |
| Hub Projection | 1/4" |
| Keyway | Yes |
| Material | Cast Iron |
| Max. Belt Width | 7/8" |
| Max. Face Width | 6.688" |
| Max. Pitch Dia. | 10.7" |
| Min. Belt Width | 7/8" |
| Min. Face Width | 6.094" |
| Min. Pitch Dia. | 8 1/2" |
| Min. Plain Bore | No |
| No. Of Grooves | 4 |
| Outside Dia. | 11.06" |
| Overall Length | 7 15/16" |
| Pitch Dia. | 8.9" to 11.1" |
| Series | MVP Series |
| Suitable For Use With | Gripbelt C Cross Section Belt |
| System Of Measurement | Imperial |
| Weight | 41.277 Kg |
| Ship weight (kg) | 40.95 |
| Ship height (cm) | 28.09 |
| Ship length (cm) | 20.17 |
| Ship width (cm) | 28.09 |
| Country of Origin | US |
