| Item | Extension Cordset |
| Cable Length | 2m |
| Connector Type | Female Straight To Male Straight |
| End 1 Gender | Male |
| End 1 Mounting Orientation | Straight |
| End 1 Number Of Pins | 5 |
| End 2 Gender | Female |
| End 2 Mounting Orientation | Straight |
| End 2 Number Of Pins | 5 |
| End Connection Size 2 | M12 |
| End Connection Type 1 | M12 |
| Features | Highly Reliable Low Resistance Contact Design With Gold Over Nickel Plating |
| Ip Rating | IP67, IP68 |
| Jacket Color | Yellow |
| Jacket Material | PVC |
| Max. Amps | 4A |
| Max. Operating Temp. | 221°F |
| Max. Voltage | 250V AC/DC |
| Min. Operating Temp. | -4°F |
| Nema Rating | NEMA 6P |
| Number Of Wires | 5 |
| Sub-brand | Micro-Change(R) |
| Wire Size | 22 AWG |
| Cable Jacket Color | Yellow |
| Cable Jacket Material | PVC |
| End 1 Connection | M12 Male |
| End 1 Connection Type | M12 |
| End 2 Connection | M12 Female |
| End 2 Connection Type | M12 |
| Maximum Current (a) | 4A |
| Maximum Operating Temperature | 221°F |
| Maximum Voltage | 250/250V DC |
| Minimum Operating Temperature | -4°F |
| Standards | CSA CERTIFIED, UL LISTED |
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Product | Model | Cable Length | Connector Type | End 1 Number Of Pins | End 2 Number Of Pins | Ip Rating | Item | Number Of Conductors | Wire Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
803000A09M020 | 2m | Female Straight | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €26.86 | |
|
803000A09M050 | 5m | Female Straight | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €36.42 | |
 |
803000A09M100 | 10m | Female Straight | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €76.21 | |
 |
803001A09M020 | 2m | Female 90° | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €35.86 | |
|
803001A09M050 | 5m | Female 90° | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €32.67 | |
|
803001A09M100 | 10m | Female 90° | 3 | - | 67,68 | Cordset | 3 | 22 AWG | €66.15 | |
|
803006A09M020 | 2m | Male Straight | 3 | - | 65 | Cordset | 3 | 24 AWG | €23.43 |
