| Item | Check Valve |
| Body Material | Brass |
| Connection Type | FNPT x MNPT |
| Max. Operating Pressure At 20°c | 12.07 Bar |
| Max. Pressure | 175 psi |
| Min. Temp. | 33°F |
| Mounting Position | Horizontal |
| Pipe Size | 1/2" |
| Seal Material | EPDM |
| Series | 4A Series |
| Size | 1/2" |
| Spring Material | Stainless Steel |
| Suitable For Central Heating Water | No |
| Body Material | Bronze |
| Check Mechanism Material | Forged Brass |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1/2" |
| Connection Size - Side 2 | 1/2" |
| Connection Type - Side 1 | IPS |
| Connection Type - Side 2 | IPS |
| Cracking Pressure | 2 psi |
| Field Testable | Not Field Testable |
| Flow Rate | 23 GPM |
| For Media | Carbonated Beverages, Water |
| Hazard Protection Level | Low Health Hazard |
| Includes Atmospheric Vent | Atmospheric Vent Included |
| Includes Freeze Protection | No Freeze Protection |
| Manufacturer Warranty | 5 yrs. |
| Max. Media Temperature | 180°F |
| Max. Pressure (cwp) | 175 psi |
| Media Temp. Range | 33°F to 180°F |
| Min. Media Temperature | 33°F |
| Mounting Orientation | Horizontal |
| Overall Height | 3 1/5" |
| Overall Length | 4.1" |
| Overall Width | 1.9" |
| Protection Type | Back Pressure, Back Siphonage |
| Seat Material | EPDM |
| Standards | ASSE 1003, IAPMO/ANSI/CAN Z1117, NSF/ANSI/CAN 372, NSF/ANSI/CAN 61 |
| Valve Series | 4A |
| Ship weight (kg) | 0.59 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 6.6 |
| Ship width (cm) | 3.56 |
| Country of Origin | CN |
