ZURN 2-850TUXL Water Pressure Reducing Valves, 2 Inch Pipe, 400 psi, Up to 350 Deg F, Female NPT
Get it by Tuesday, Jun 17
€539.06 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Valve |
| Ball Material | Bronze |
| Connection Type | FNPT |
| Max. Pressure | 400 psi |
| Overall Length | 4 1/2" |
| Pipe Size | 2" |
| Temp. Range | 0°F to +350°F |
| 3-a Compliance | Not Rated |
| Ball Port Style | Full Port |
| Body Material | Bronze |
| Coefficient Of Volume (cv) | Not Rated |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 2" |
| Connection Size - Side 2 | 2" |
| Connection Type - Side 1 | NPT |
| Connection Type - Side 2 | NPT |
| For Media | Air, Combustible Gases, Steam, Water |
| Handle | Lever |
| Handle Color | Green |
| Handle Height | 3.88" |
| Handle Length | 4 3/4" |
| Handle Material | Stainless Steel |
| Max. Pressure (combustible Gas) | Not Rated |
| Max. Pressure (cwp) | 400 psi |
| Max. Pressure (steam) | 400 psi |
| Media Temp. Range | 33°F to 350°F |
| Nominal Valve Size | 2" |
| Seat Material | TFE |
| Standards | ANSI B1.20.1, NSF/ANSI 372 |
| Stem Material | Brass |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Straight |
| Valve Construction | One-Piece |
| Valve Series | 850XL |
| Vented Ball Valve | Non Vented |
| Ship weight (kg) | 2.93 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 11.43 |
| Ship width (cm) | 2.54 |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
12-850XL | Ball Valve | €44.65 | |
 |
112-850TXL | Valve | €188.40 | |
 |
2-850XL | Valve | €269.53 | |
 |
112-850UXL | Valve | €379.52 | |
 |
112-850TUXL | Valve | €388.23 |
