| Item | General Purpose Filter |
| Air Inlet Size | 3/4" |
| Air Outlet Size | 3/4" |
| Body Material | Aluminum |
| Bowl Material | Plastic |
| Drain Included | Yes |
| Drain Type | Manual |
| Element Material | Sintered Polyethylene |
| Filter Bowl Capacity | 2.87 oz. |
| Filter Bowl Guard Material | Plastic |
| Filter Media | Sintered Polyethylene |
| Filter Rating | 5 µm |
| Filter Type | Particulate |
| For Fluid Type | Water |
| For Removal Of | Particles, Water |
| For Substance Type | Water, Particulate Contamination |
| Gauge Included | No |
| Max. Incoming Pressure | 150 psi |
| Max. Operating Pressure | 150 psi |
| Max. Temp. | 125°F |
| Modular Connection | Modular Connection |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Overall Height | 9 1/4" |
| Overall Width | 2 7/8" , 2.87" |
| Pressure Drop | 4.9 psid |
| Seal Material | Nitrile |
| System Location | Air Line |
| Air Inlet Type | NPT |
| Air Outlet Type | NPT |
| Connection Style | Air Line |
| Filter Bowl Material | Polycarbonate |
| Filter Element Material | Sintered Polyethylene |
| Iso Class | Class 3 |
| Maximum Flow Rate | 145 CFM |
| Maximum Operating Pressure | 150 psi |
| Maximum Operating Temperature | 125°F |
| Minimum Operating Temperature | -13°F |
| Overall Depth | 2 7/8" |
| Series | F28 Series |
| Weight | 1.01 lbs. |
| Ship weight (kg) | 0.6 |
| Ship height (cm) | 23.5 |
| Ship length (cm) | 7.3 |
| Ship width (cm) | 7.3 |
| Country of Origin | US |
