| Item | Carbon Filter |
| Air Inlet Size | 3/4" |
| Air Outlet Size | 3/4" |
| Body Material | Aluminum |
| Bowl Material | Metal |
| Drain Included | Yes |
| Drain Type | Manual |
| Element Material | Borosilicate Fiber |
| Filter Bowl Capacity | 3 oz. |
| Filter Bowl Guard Included | Yes |
| Filter Media | Carbon |
| Filter Rating | 0.5 µm |
| Filter Type | Activated Carbon |
| For Removal Of | Odor, Oil Vapor |
| For Substance Type | Desiccant Dust |
| Gauge Included | No |
| Max. Incoming Pressure | 250 psi |
| Max. Operating Pressure | 150 psi |
| Max. Temp. | 250°F |
| Modular Connection | Modular Connection |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Overall Height | 9 1/4" |
| Overall Width | 2 7/8" , 2.87" |
| Pressure Drop | 3 psid |
| Seal Material | Nitrile |
| Sight Gauge Included | Yes |
| System Location | Air Line |
| Air Inlet Type | NPT |
| Air Outlet Type | NPT |
| Connection Style | Air Line |
| Filter Bowl Material | Metal |
| Filter Element Material | Borosilicate Fiber |
| Iso Class | Class 2, Class 3 |
| Maximum Flow Rate | 98 CFM |
| Maximum Operating Pressure | 150 psi |
| Maximum Operating Temperature | 150°F |
| Minimum Operating Temperature | -13°F |
| Overall Depth | 2 7/8" |
| Series | A28 Series |
| Weight | 1.01 lbs. |
| Ship weight (kg) | 0.79 |
| Ship height (cm) | 23.5 |
| Ship length (cm) | 7.3 |
| Ship width (cm) | 7.3 |
| Country of Origin | US |
