| Item | Turning Insert |
| Ansi Code | WCMW2(1.5)0.5 |
| Applications | Roughing |
| Coating | Uncoated |
| Cutting Direction | Neutral |
| Grade | Grade WCD10 |
| Inscribed Circle | 1/4" |
| Insert Material | Carbide |
| Iso Number | WCMW040202WCD10 |
| Mounting Style | Screw Clamp |
| No. Of Edges | 3 |
| Primary Application | Roughing |
| Rake | Positive |
| Relief Angle | 7° |
| Shape | Trigon |
| Style | WCMW |
| Thickness | 0.093" |
| Chip-breaker | Yes |
| Chip-breaker Code | A27 |
| Clearance Angle | 7° |
| Corner Radius | 0.2 mm |
| Cutting Application | Boring |
| Cutting Edge Length | 4.3 mm |
| Feed Type | High |
| Included Angle | 80° |
| Insert Code | WCMW21.5.5 |
| Insert Holding Type | 40° to 60°Countersink Hole |
| Insert Style | WCMW |
| Manufacturer Grade | WCD10 |
| Material - Machining | Polycrystalline Diamond |
| Measurement System | Metric |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Magnesium |
| Primary Material Application Iso Code | N |
| Ship weight (kg) | 0.06 |
| Ship height (cm) | 1.5 |
| Ship length (cm) | 4.19 |
| Ship width (cm) | 3.99 |
| Country of Origin | DE |
| Model | Ansi Number | Grade | Insert Size | Insert Thickness | Price | |
|---|---|---|---|---|---|---|
| WCMW040202 WCB50 | WCMW2(1.5)0.5 | WCB50 | 4 | 0.093" | €105.84 | |
| WCMW040204 WCB50 | WCMW2(1.5)1 | WCB50 | 4 | 0.093" | €105.84 | |
| WCMW040204 WCD10 | WCMW2(1.5)1 | WCD10 | 4 | 0.093" | €141.02 | |
| WCMW050304 WCB50 | WCMW2.5(2)1 | WCB50 | 5 | 0.125" | €105.84 | |
| WCMW050304 WCD10 | WCMW2.5(2)1 | WCD10 | 5 | 0.125" | €147.49 |
