| Item | Fitting |
| Application | Compressed Air, Hydronics, Industrial Gases, Marine |
| Compatible Tube Material | Stainless Steel |
| Finish/coating | Zinc Nickel |
| Fitting Material | Stainless Steel |
| Fitting Side A Connection Type | Press Fit |
| Fitting Side A Pipe Size | 4" |
| Fitting Side A Tube Outer Diameter | 4" |
| Fitting Side B Connection Type | Press Fit |
| Fitting Side B Pipe Size | 4" |
| Fitting Side B Tube Outer Diameter | 4" |
| Max. Operating Pressure | 200 psi |
| O-ring Material | FKM |
| Overall Length | 5.906" |
| Specific Fitting Angle | 45° |
| Specific Fitting Shape | 45° Elbow |
| Thread Sealant Type | FKM |
| Includes Pre-applied Thread Sealant | Yes |
| Material Grade | Grade 316 |
| Maximum Operating Pressure | 200 |
| Maximum Operating Temperature | 250°F |
| Standards | ASTM, FM LISTED, UL LISTED |
| Ship weight (kg) | 2.79 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
