| Item | Invertible Fork Material Lift |
| Capacity | 500 lbs. |
| Color | Silver |
| Depth | 35.125" |
| Design | Standard |
| Fork Height | 1 3/4" |
| Fork Length | 22 7/16" |
| Fork Lowered Height | 3.5" |
| Fork Outside Dia. | 20 1/2" |
| Fork Raise per Hand Crank Rotation | 1" |
| Fork Saddle Width | 20.5" |
| Fork Thickness | 1.75" |
| Fork Width | 4" |
| Frame Material | Steel |
| Front Wheel Dia. | 2" |
| Front Wheel Type | Swivel |
| Handle Length | 18.63" |
| Handle Material | Steel |
| Height | 68.75" |
| Inside Straddle Width | 12 1/2" |
| Length | 35.13" |
| Lifting Height Forks Down | 47 In. |
| Lifting Height Forks Up | 67 In. |
| Lifting Height Max. | 47" |
| Lowered Height | 3 1/2" or 23 1/2" |
| Material | Aluminum, Steel |
| Max. Adjustable Fork Width | 20.5" |
| Max. Fork Height | 67" |
| Measuring Units | EACH |
| Outside Dia. | 20-1/2" |
| Outside Straddle Width | 20 1/2" |
| Power Source | Hand |
| Product Datasheet | vestil-rp-a-lift-r.pdf |
| Raised Height with Forks Down | 47" |
| Raised Height with Forks Up | 67" |
| Rear Wheel Dia. | 8" |
| Width | 23.94" |
| Ship weight (kg) | 61.2 |
| Ship height (cm) | 174.63 |
| Ship length (cm) | 89.22 |
| Ship width (cm) | 60.8 |
| HS code | 8427900000 |
| Country of Origin | CN |
| Product | Model | Item | Inside Straddle Width | Capacity | Depth | Lifting Height Max. | Max. Adjustable Fork Width | Max. Fork Height | Outside Straddle Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
A-LIFT-R-HP | Hand Winch Lift Truck | 12 3/4" | 400 lbs. | 35" | 97" | 20.88" | 117" | 20 7/8" | €2,940.42 | |
 |
A-LIFT-S | Invertible Fork Straddle Lift | 21 3/4" to 36 1/4" | 500 lbs. | 42.5" | 47.25" | 43.88" | 68.88" | 29" to 43 7/8" | €1,997.20 | |
 |
A-LIFT-S-EHP | Invertible Fork Straddle Lift | 21 3/4" to 36 1/4" | 350 lbs. | 42.5" | 122" | 43.88" | 143.69" | 29" to 43 7/8" | €2,316.51 | RFQ
|
 |
A-LIFT-S-HP | Invertible Fork Straddle Lift | 21 3/4" to 36 1/4" | 400 lbs. | 42.5" | 98.44" | 43.88" | 120" | 29" to 43 7/8" | €2,413.93 |
