| Item | Check Valve |
| Application | General Purpose |
| Application - Valves | General Purpose |
| Body Material | PVC |
| Connection Type | Slip x Slip |
| Cracking Pressure | 1/2 psi |
| Flow Design | Single |
| Flow Rate | 100 GPM |
| Full Flow | No |
| Full Flow - Valves | No |
| Length | 2.812" |
| Max. Steam Pressure | Not Rated |
| Max. Steam Pressure - Valves | Not Rated |
| Max. Temp. | 73°F |
| Max. Water Pressure | 150 psi |
| Mechanism And Body Design | Inline Spring Swing |
| Min. Temp. | 35°F |
| Mounting Orientation | Horizontal, Vertical , Horizontal/Vertical |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Overall Height | 5" |
| Pipe Or Tube Size | 1" |
| Pipe Or Tube Size - Check Valves | 1" |
| Pipe Size, Tube Size | 1" |
| Seal Material | Nbr |
| Seat Material | PVC |
| Spring Material | Stainless Steel |
| Spring Material - Check Valves | Stainless Steel |
| Width | 2.812" |
| 3-a Compliance | Not Rated |
| Check Mechanism | Swing |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1" |
| Connection Size - Side 2 | 1" |
| Connection Type - Side 1 | Socket |
| Connection Type - Side 2 | Socket |
| Disc Material | 316 Stainless Steel |
| For Media | Water |
| Max. Pressure (cwp) | 150 psi |
| Max. Pressure (steam) | Not Rated |
| Media Temp. Range | 35°F to 73°F |
| Operating Temperature - Maximum | 73°F |
| Operating Temperature - Minimum | 35°F |
| Overall Length | 2.81" |
| Pipe Size | 1" |
| Silent Check | Standard |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Inline |
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 12.7 |
| Ship length (cm) | 7.14 |
| Ship width (cm) | 7.14 |
| Country of Origin | US |
