| Item | Combination Strainer/Ball Valve |
| Ball Material | Stainless Steel |
| Ball Material Grade | Grade 304 |
| Body Material | Stainless Steel |
| Body Material Grade | Grade 304 |
| Connection Type | FNPT x FNPT |
| Handle Material Grade | Grade 304 |
| Max. Pressure | 800 psi WOG |
| Pipe Size | 1/2" |
| Port | Standard |
| Screen Material Grade | Grade 304 |
| Stem Grade | Grade 304 |
| Stem Material | Stainless Steel |
| Temp. Range | -20°F to +230°F |
| Ball Port Style | Standard Port |
| Bypass Connection | 1/2" FNPT |
| For Media | Natural Gas, Steam, Water |
| Handle Material | Grade 304 Stainless Steel |
| Max. Pressure (cwp) | 800 psi |
| Media Temp. Range | -20°F to 230°F |
| Nominal Valve Size | 1/2" |
| Operating Temperature - Maximum | 230°F |
| Operating Temperature - Minimum | -20°F |
| Outlet Connection Gender - Side 1 | Female |
| Outlet Connection Gender - Side 2 | Female |
| Outlet Connection Size - Side 1 | 1/2" |
| Outlet Connection Size - Side 2 | 1/2" |
| Outlet Connection Type - Side 1 | NPT |
| Outlet Connection Type - Side 2 | NPT |
| Screen Material | 304 Stainless Steel |
| Seat Material | FKM |
| Standards | ANSI/ASME B1.20.1 |
| Ship weight (kg) | 2.7 |
| Country of Origin | CN |
| Model | Price | |
|---|---|---|
| ZUSA-VLV-62 | €152.81 | |
| ZUSA-VLV-61 | €98.73 | |
| ZUSA-VLV-63 | €201.53 | |
| ZUSA-VLV-60 | €63.87 |
