TRITAN 100BS19H X 1 1/4 Roller Chain Sprocket, 1 1/4 Inch Bore Dia, 19 Teeth, Steel
€282.45 /unit
Request a Quote
Payment
Payment
| Item | Roller Chain Sprocket |
| Bore Dia. | 1 1/4" |
| Bore Type | Fixed |
| Chain Number | 100 |
| Finish | Black Oxide |
| For Chain Number | 100.0 |
| For Chain Pitch | 1 1/4" |
| For Number Of Strands | 1 |
| Hub Dia. | 4 1/2" |
| Hub Projection | 1.371" |
| Hub Type | One Side |
| Includes | Set Screws |
| Industry Chain Size | 100 |
| Item - Roller Chain Sprockets | Roller Chain Sprocket |
| Keyway | Yes |
| Keyway Width | 1/4" |
| Length Through Bore | 2" |
| Material | Steel |
| Maximum Bore Dia. | 1 1/4" |
| Number Of Set Screws | 2 |
| Number Of Teeth | 19 |
| Outside Dia. | 8 6/25" |
| Pitch Dia. | 7.595" |
| Set Screw Location | One Setscrew Over The Keyway And A Second Setscrew at 90° |
| Set Screw Size | 0.312" |
| Teeth Heat Treatment | Hardened Teeth |
| Tooth Width | 0.692" |
| Width Across Tooth Sets | Not Applicable |
| Bore Diameter | 1 1/4" |
| Hub Diameter | 4 1/2" |
| Maximum Bore Diameter | 1 1/4" |
| Outside Diameter | 8.24" |
| Pitch Diameter | 7.595" |
| Standards | ANSI B29.1, BIS |
| Ship weight (kg) | 5.9 |
| Ship length (cm) | 20.93 |
| Ship width (cm) | 20.93 |
| Country of Origin | CN |
| Model | Price | |
|---|---|---|
| D80BS12H X 1 1/2 | €147.75 | RFQ
|
| D60BS13H X 1 1/2 | €84.53 | RFQ
|
| D80BS13H X 1 1/2 | €150.28 | RFQ
|
| D60BS14H X 1 1/2 | €94.45 | RFQ
|
| 60BS16H X 1 1/2 | €88.94 | |
| 50BS17H X 1 1/2 | €54.77 | |
| 80BS17H X 1 1/2 | €126.52 |
