| Item | Rectangular Proximity Sensor |
| Application | General Purpose |
| Basic Material | Plastic |
| Basic Proximity Sensor Case Material | Plastic |
| Body Type | Fixed |
| Case Material | Plastic |
| Circuit Type | 2 Wire |
| Depth | 26 mm |
| Description/special Features | Auto Adaptable |
| Detecting Distance | 60 mm |
| Ip Rating | IP68, IP69K |
| Length | 103 mm |
| Max. Delay First Up | 0.3 ms , 15 ms , 6 ms |
| Max. Detecting Distance | 60 mm |
| Max. Load Amps | 200 mA |
| Max. Load Current | 200 mA |
| Number Of Wires | 2 |
| Operating Frequency | 150 Hz |
| Operating Temp. Range | -13°F to +158°F |
| Output Mode | No |
| Power Required | 24-240V |
| Proximity Sensing Method | Inductive |
| Proximity Sensor Operating Frequency | 150 Hz |
| Sensing Method | Inductive |
| Shielded / Unshielded | Shielded |
| Width | 80 mm |
| Ac Supply Voltage Rating | 24-240V AC |
| Body Material | PBT |
| Dc Supply Voltage Rating | 24-240V DC |
| Display Qty | 1 |
| Electrical Connection | Bare Wire |
| Electrical Installation Type | Prewired Cable |
| Features | Auto Adaptable |
| Includes Indicator Lights | No Indicator Lights Included |
| Load Current - Maximum | 300 mA |
| Nema Enclosure Rating | 4X |
| Operating Temperature - Maximum | 158°F |
| Operating Temperature - Minimum | -13°F |
| Output Circuit | 2 Wire AC/DC |
| Output Circuit Contact Form | NO |
| Output Circuit Type | AC, DC-Type |
| Overall Depth | 80 mm |
| Overall Height | 26 mm |
| Overall Width | 80 mm |
| Sensing Distance - Maximum | 60 mm |
| Sensing Face Shielding | Shielded |
| Sensor Body Style | Rectangular |
| Sensor Cable Length | 2m |
| Series | XS8 Series |
| Standards | CCC, CE, CSA, ECOLAB, ROHS, UL LISTED |
| Supply Voltage | 24-240V AC, 24-240V DC |
| Ship weight (kg) | 0.42 |
| Ship height (cm) | 13 |
| Ship length (cm) | 6.6 |
| Ship width (cm) | 9.5 |
| Country of Origin | FR |
| Product | Model | Case Material | Circuit Type | Depth | Electrical Connection | Ip Rating | Length | Nema Rating | Operating Frequency | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
XS7D1A1PAM12 | Plastic | PNP | 26mm | 4 Pin M12 Male Connector | 67 | 80mm | 4X | 100 Hz | €268.00 | |
|
XS7E1A1DAL2 | Plastic | 2 Wire | 13mm | 2m Cable | 68, 69K | 40mm | 4X | 1000 Hz | - | RFQ
|
 |
XS8C1A1MAL2 | Plastic | 2 Wire | 15mm | 2m Cable | 68, 69K | 54mm | 4X | 1000 Hz | €213.69 | |
 |
XS9C111A2L2 | Plastic | 2 Wire | 15mm | 2m Cable | 68, 69K | 54mm | 4X | 1000 Hz | - | RFQ
|
 |
XS7C4A1DPG13 | PBT | 2 Wire | 117mm | PG13, Screw Terminal | 65, 67, 69K | 40mm | - | 300 Hz | €272.26 | |
|
XS7C4A1MPG13 | PBT | 2 Wire | 117mm | PG13, Screw Terminal | 65, 67, 69K | 40mm | - | 300 Hz | €318.54 | |
|
XS8C4A1NCG13 | PBT | 4 Wire NPN | 117mm | PG13, Screw Terminal | 65, 67, 69K | 40mm | - | 300 Hz | €238.68 |
