| Item | Circuit Breaker |
| Ac Voltage Rating | 600V AC |
| Amps | 700A |
| Circuit Breaker Type | Standard |
| Dc Voltage | Not Rated |
| Depth | 8.1" |
| Frame Size | M |
| Height | 12.9" |
| High Amp Trip Setting | 7000A |
| Low Amp Trip Setting | 1400A |
| Max. Air Rating | 25 kA |
| Max. Wire Size | 500 kcmil |
| Min. Wire Size | 3/0 AWG |
| Mounting | Panel |
| Number Of Poles | 3 |
| Phase | 3 |
| Phase Connection | ABC |
| Terminal Connection Type | Box Lug |
| Trip Type | Electronic |
| Width | 8.3" |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Panel Mount |
| Dc Voltage Rating | Not Rated |
| For Use With | I Line Panelboards |
| Instantaneous Trip | Adjustable |
| Standards | CSA, IEC, UL LISTED |
| Terminal Connection | Box Lug |
| Ship weight (kg) | 12.94 |
| Ship height (cm) | 32.77 |
| Ship length (cm) | 20.57 |
| Ship width (cm) | 21.08 |
| HS code | 8536200020 |
| Country of Origin | US |
Contact your account manager right away to get personal advice.
We're available Monday through Friday, from 07:30 until 17:00.
In Stock : 4 Units
