Get it by Tuesday, Jun 17
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
Payment
| Item | Terminal Block |
| Color | Gray |
| Connection Type | Screw Clamp |
| Depth | 1 18/25" |
| Height | 1.79" |
| Material | Nylon |
| Min. Wire Size | 22 AWG |
| Mounting Style | DIN |
| Number Of Connections | 2 |
| Number Of Poles | 1 |
| Temp. Range | -40°F to +275°F |
| Temp. Rating | -40°F to 257°F |
| Terminal Type | Solderless Box Lug |
| Voltage | 600V AC |
| Width | 569011" |
| 2-pole Jumper Compatibility | 5B368 |
| 6-pole Jumper Compatibility | 5B367 |
| Circuit Protection Type | None |
| Compatible Grainger Part Number | 5B361 |
| Compatible Manufacturer Model Number | GM6B |
| Current | 30A |
| End Barrier Compatibility | 5B373 |
| Flammability Rating | V-2 |
| For Channel Rail Size | 35 mm |
| For Conductor Material | Copper |
| For Conductor Type | Solid, Stranded |
| For Fuse Diameter | 3 1/32" |
| For Maximum Wire Size | 10 AWG |
| For Minimum Wire Size | 22 AWG |
| Housing Color | Gray |
| Housing Material | Nylon |
| Includes | End Barrier |
| Maximum Operating Temperature | 257°F |
| Maximum Voltage | 600V AC/DC |
| Minimum Operating Temperature | -40°F |
| Mounting Type | DIN |
| Number Of Tiers | 2 |
| Overall Depth | 0.24" |
| Overall Length | 1.82" |
| Overall Width | 1 18/25" |
| Pieces Per Foot | 51 |
| Rohs Compliant | Yes |
| Standards | CE, CSA APPROVED, ROHS COMPLIANT, UL COMPONENT RECOGNIZED |
| Terminal Block Type | Solderless Box Lug |
| Terminal Material | Zinc Plated Steel |
| Termination Style | Screw |
| Torque | 8 lbs.-in. |
| Ship weight (kg) | 0.01 |
| Ship height (cm) | 4.29 |
| Ship length (cm) | 4.29 |
| Ship width (cm) | 0.79 |
| HS code | 8536904000 |
| Country of Origin | MX |
| Product | Model | Amps | Color | Depth | Height | Item | Max. Wire Size | Min. Wire Size | Terminal Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
9080GE6 | 255 | Natural | 3.32" | 2.34" | Terminal Block | 250MCM | 6 AWG | Solderless Box Lug | €46.31 | |
 |
9080GMB6 | 30 | Black | 1.72" | 1.79" | Terminal Block | 10 AWG | 22 AWG | Solderless Box Lug | €3.39 | |
 |
9080GM6 | 30 | Natural | 1.72" | 1.79" | Terminal Block | 10 AWG | 22 AWG | Solderless Box Lug | €3.85 | |
 |
9080GD6 | 170 | Natural | 2.12" | 2.71" | Terminal Block | 1/0 AWG | 12 AWG | Pass-Through | €18.23 | |
 |
9080GC6 | 85 | Natural | 1.99" | 2.13" | Terminal Block | 4 AWG | 18 AWG | Pass-Through | €8.90 | |
 |
9080GR6 | 60 | Natural | 1.72" | 1.79" | Terminal Block | 8 AWG | 22 AWG | Solderless Box Lug | €4.84 | |
 |
9080GS6 | - | - | - | - | Terminal | - | - | - | €8.16 |
