| Item | Steam Trap |
| Application | Steam Lines, Process Equipment, Steam Tracing, Unit Heaters, Coils And Rotating Drums |
| Body Material Grade | Stainless Steel |
| Condensate Capacity | 580 lbs./hr. |
| Disc Grade | Grade 304 |
| Disc Material | Stainless Steel |
| Downstream Pressure Range | 0 psi to 400 psi |
| End To End Length | 4" |
| Max. Operating Pressure | 400 psi |
| Max. Temp. | 800°F |
| Pipe Configuration | Straight |
| Type | Inverted Bucket |
| Allowable Pressure - Maximum | 307 psi |
| Body Material | Stainless Steel |
| Configuration | In-line |
| Distance Between Inlet And Outlet Port | 4" |
| Float Material | Stainless Steel |
| Gasket Material | Graphite Fiber |
| Includes Strainer | Strainer Not Included |
| Installation Orientation | Horizontal |
| Manufacturer Series | Dura Flo |
| Max. Condensate Capacity | 580 lbs./hr. |
| Max. Operating Temperature | 800°F |
| Mounting | Mounting Block |
| Number Of Ports | 2 |
| Orifice Diameter | 1/16" |
| Overall Depth | 7 3/16" |
| Overall Length | 4" |
| Port Connection Size | 2 3/4" |
| Port Connection Type | Flange UMT |
| Resistance Properties | Water Hammer Resistant |
| Steam Trap Type | Inverted Bucket |
| Ship weight (kg) | 1.69 |
