| Item | Extension Spring |
| Deflection @ Load | 2.39" |
| End Type | Full Twist Loop |
| Finish | Passivated |
| Grade | Grade 302 |
| Initial Tension | 1.29 lbs. |
| Load | 14.38 lbs. |
| Material | Stainless Steel |
| Meets/exceeds | ASTM-A313 AND AMS-5688 |
| Outside Dia. | 3/4" |
| Overall Length | 2 1/2" |
| Spring Rate | 5.5 lbs.-in. |
| Type | High Precision |
| Wire Dia. | 0.069" |
| Extended Length | 4 57/64" |
| Free Length | 2 1/2" |
| Outside Diameter | 0.75" |
| Product Type | Extension Spring |
| Standards | AMS 5688, ASTM A313 |
| System Of Measurement | Imperial |
| Wire Diameter | 0.069" |
| Ship weight (kg) | 0.02 |
| Model | Pkg. Qty. | Price | |
|---|---|---|---|
| E02400372250X | 10 | €69.15 | |
| DE0500011000M | 2 | €46.50 | |
| DE0625011000M | 2 | €48.09 | |
| DE0625011200M | 2 | €54.78 | |
| DE0500011200M | 2 | €45.66 | |
| DE0250010200M | 2 | €38.24 | |
| DE0375010200M | 2 | €38.97 |
