| Item | Seal |
| Accuracy | -1% to +1% |
| Accuracy Grade | ASME B40.100 Grade 1A |
| Accuracy Scale | Full Scale |
| Adjustable Pointer | No |
| Ambient Temp. Range | -40°F to +150°F |
| Application | Fire Apparatus, Hydraulics, Marine, Military, Transportation, Water Treatment Applications , Mobile Hydraulic Equipment, Fire Apparatus, Water Purification/Irrigation, Bulk Transport Trailers, Waste Water/Slurry, Military, Marine , Transportation, Fire Apparatus, Marine, Military, Hydraulics, Water Treatment Applications |
| Basic Gauge Case Material | Plastic |
| Basic Gauge Sensor Material | Copper |
| Basic Gauge Socket Material | Brass |
| Bezel Material | Zytel Nylon |
| Bezel Mounting Type | Removable |
| Blowout Safety Back | No |
| Calibration Certificate Included | No |
| Case Color | Black |
| Case Construction | Chemical Resistant, Corrosion Resistant, Weather Resistant |
| Case Depth | 1.41" |
| Case Dia. | 3 1/5" |
| Case Finish | Gloss |
| Case Material | Zytel Nylon |
| Cleaned For Oxygen Service | No |
| Clog Resistant | Yes |
| Color | Black |
| Connection Location | Bottom |
| Dial Color | White |
| Dial Face Material | Aluminum |
| Diaphragm Seal Type | Clamped |
| Dry Dampening Feature | None |
| Field Fillable | Yes |
| Freeze Resistant Movement | Yes |
| Gauge Case Color | Black |
| Gauge Case Liquid | Glycerin |
| Gauge Connection Location | Bottom |
| Gauge Connection Size | 1/4" |
| Gauge Filled With | Glycerin |
| Gauge Nominal Dial Size | 2 1/2" |
| Gauge Panel Mountable | No |
| Gauge Primary Range No.ed Graduations | 10 |
| Gauge Primary Range Units | Psi |
| Graduations | 10 psi |
| Hazardous Location Rating | Not Rated |
| Includes | Buna-N Anti-Freeze/Anti-Clog Barrier |
| Includes Mounting Hardware | No |
| Includes Vent Plug | No |
| Ip Rating, Nema Rating | IP65, NEMA 4X |
| Lens Material | Acrylic , Plastic |
| Liquid Filled | Yes |
| Liquid-filled Case | Yes |
| Mfr. Series | LFS-210 |
| Mounting Hardware Included | No |
| Mounting Type | Stem Mount |
| Movement Material | Copper Alloy |
| Movement Type | Swiss |
| Nominal Dial Size | 2 1/2" |
| Panel-mountable | No |
| Pointer Color | Black |
| Pointer Material | Aluminum |
| Pressure And Vacuum Gauge Type | Pressure Gauge |
| Pressure Gauge Type | Industrial Pressure Gauge With Diaphragm Seal |
| Pressure Range | 0 psi to 100 psi |
| Pressure Range Type | Pressure |
| Primary Scale Minor Graduations | 1 |
| Primary Scale Numeric Increments | 10 , 10.0 |
| Primary Scale Units | Psi |
| Process Connection Gender | Male |
| Process Connection Location | Bottom |
| Process Connection Size | 1/4" |
| Process Connection Type | NPT |
| Process Temperature Range | -40°F to +150°F |
| Range | 0 psi to 100 psi |
| Removable Bezel | Yes |
| Scale Type | Single |
| Seal Compatible Process Media | Water, Oil, Gases and Liquids |
| Seal Diaphragm Material | Buna N |
| Seal Fill Liquid | Instrument Oil |
| Seal Lower Housing Material | Brass |
| Sensor Material | Copper Alloy |
| Sensor Type | Bourdon Tube |
| Smallest Graduation | 1 psi |
| Socket Material | Brass |
| Vibration Resistance | Liquid Filled |
| Ambient Operating Temperature Range | -40°F to +150°F |
| Case Diameter | 3.2" |
| Gauge Case Material | Zytel Nylon |
| Includes Calibration Certificate | No |
| Ip/nema Rating | IP65, NEMA 4X |
| Primary Pressure Range | 0 to 100 |
| Process Connection | 1/4" NPT Male |
| Series | LFS-210 Series |
| Standards | ANSI/ASME B40.1 |
| Wetted Parts Material | Brass, Copper Alloy |
| Ship weight (kg) | 0.38 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
LFS-210-30Hg/150PSI-G-KEMX | Compound Gauge | €95.67 | |
 |
LFS-210-30Hg/300PSI-G-KEMX | Compound Gauge | €56.28 | |
 |
LFS-210-30Hg/60PSI-G-KEMX | Compound Gauge | €95.67 | |
 |
LFS-210-30Hg/600PSI-G-KEMX | Compound Gauge | €95.67 | |
 |
LFS-210-1000-G-KEMX | Seal | €56.28 | |
 |
LFS-210-1500-G-KEMX | Seal | €95.67 | |
 |
LFS-210-15-G-KEMX | Seal | €56.28 |
