| Item | Manual Motor Starter |
| Amps Rating | 1.6A |
| Connection Type | Screw Connection |
| Depth | 96 mm |
| Enclosure Nema Rating | No Enclosure |
| Height | 97 mm |
| Horsepower @ Three Phase | 3/4 hp |
| Hp @ 1 Phase - 230v | 1/10 hp |
| Hp @ 3 Phase - 460-575v | 3/4 hp |
| Hp @ 3 Phase - 480v | 3/4 hp |
| Hp @ 3 Phase - 575v | 3/4 hp |
| Hp @ Single Phase - 240v Ac | 1/10 hp |
| Integrated Auxiliary Switch Present | No |
| Integrated Undervoltage Tripper Present | No |
| Manner Of Using | Toggle |
| Max. Overload Relay Amps Setting | 1.6A |
| Max. Voltage | 600V AC |
| Mounting Hole Dia. | 1.38" |
| Nema Size | Not Applicable |
| Number Of Auxiliary Contacts As Opener | 0 |
| Number Of Auxiliary Contacts As Shutter | 0 |
| Number Of Poles | 3 |
| Operator | Selector Switch |
| Overall Depth | 4.35" |
| Overall Height | 4.7" |
| Overall Width | 4.35" |
| Overload Protection Type | Thermal |
| Overload Relay Amp Setting | 1.1-1.6A |
| Phase Loss Sensitivity | No |
| Pilot Light | No |
| Pole Number | 3 |
| Release System | Magnetic |
| Sensitive To Phase Failure | Yes |
| Terminal Connection Type | Screw Terminals |
| Width | 45 mm |
| Electrical Operating Durability | 100000 |
| Frame Size | S00 |
| Frequency | 50/60 Hz |
| Horsepower @ Single Phase - 240v Ac | 1/10 hp |
| Horsepower @ Three Phase - 480v Ac | 3/4 hp |
| Horsepower @ Three Phase - 600v Ac | 3/4 hp |
| Includes Pilot Light | No |
| Ip Rating | IP20 |
| Max Current (ac) | 1.6A |
| Maximum Operating Temperature | 140°F |
| Maximum Overload Relay Current Setting | 1.6A |
| Maximum Voltage Rating | 690V AC |
| Mechanical Operating Durability | 100000 |
| Minimum Operating Temperature | -4°F |
| Minimum Overload Relay Current Setting | 1.1A |
| Mounting Hole Diameter | 1.38" |
| Mounting Style | DIN Rail |
| Nema Enclosure Rating | No Enclosure |
| Phase | Three |
| Reversing Capability | Non-Reversing |
| Series | Sirius 3RV20 |
| Standards | ECLASS 27-37-04-01, ETIM EC000074, ETIM EC000074 IDEA 4845 |
| Starter Style | IEC |
| Thermal Units Required | None (Starter Includes Integrated Thermal Units) |
| Trip Class | 10 |
| Wire Termination Type | Screws |
| Ship weight (kg) | 0.34 |
| Ship height (cm) | 11.94 |
| Ship length (cm) | 11.05 |
| Ship width (cm) | 11.05 |
| Country of Origin | DE |
| Model | Price | |
|---|---|---|
| 3RV20110GA10 | €175.25 | |
| 3RV20110HA10 | €221.00 | |
| 3RV20110JA10 | €262.17 | |
| 3RV20110KA10 | €199.91 | |
| 3RV20111BA10 | €196.88 | |
| 3RV20111CA10 | €337.15 | |
| 3RV20214AA10 | €286.26 |
