| Item | Solid State Relay |
| Body Depth | 3 19/25" , 3.14" |
| Body Height | 3.94" |
| Body Width | 1.77" , 2 1/5" |
| Case Color | Black |
| Current Type | DC |
| Electrical Connection | Screw , Screw Clamp |
| Electrical Phase | 3 |
| Finger Safe | Yes |
| Frequency | 50/60 Hz |
| Heat Sink | Integral |
| Input Amps | 10A |
| Input Current | 10A |
| Input Voltage | 4-30V DC |
| Ip Rating | IP20 |
| Max. Operating Temp. | 140°F |
| Maximum Output Current With Heat Sink | 10A |
| Mfr. Series | Sirius 3Rf2 Series |
| Min. Operating Temp. | -13°F |
| Modular Version | Yes |
| Number Of Phases | 3 |
| Output Switching Mode | Zero Crossing |
| Output Voltage Range | 48-600V AC |
| Overall Depth | 3.77" |
| Overall Height | 3.94" |
| Relay Mounting Style | Din Rail |
| Relay Turns On At | Zero Crossing |
| Response Time | 1 ms |
| Voltage/current Type | AC Output |
| Electrical Connection Type | Screw |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -13°F |
| Output Voltage | 48-600V AC |
| Series | SIRIUS 3RF2 Series |
| Standards | C-TICK (RCM), CCC, CE CERTIFIED, CSA CERTIFIED, EAC, UL LISTED |
| Ship weight (kg) | 0.28 |
| Ship height (cm) | 10.01 |
| Ship length (cm) | 7.98 |
| Ship width (cm) | 5.59 |
| Country of Origin | DE |
| Product | Model | Price | |
|---|---|---|---|
 |
3RF2310-1AA04 | €208.65 | |
|
3RF2310-1AA02 | €207.90 | |
 |
3RF2320-1AA02 | €222.76 | |
 |
3RF2420-1AC45 | €649.41 | |
|
3RF2320-1AA24 | €245.92 | |
|
3RF2320-1AA04 | €268.86 | |
 |
3RF2330-1AA04 | €253.79 |
