| Ability To Relubricate | No |
| Bearing Insert Finish | Black Oxide |
| Bearing Insert Material | Steel |
| Bearing Insert Material Grade | 52100 |
| Bearing Insert Type | Standard Duty |
| Bore Dia. | 3/4" |
| Bore Diameter | 3/4" |
| Bore Shape | Straight |
| Cage Material | Molded Nylon |
| Cage Type | Land Riding Retainer |
| Centerline To Outermost Bearing Face | 0.87" |
| Closure | Double Sealed |
| Dynamic Load Capacity | 2611 lbs. |
| Dynamic Radial Load Capacity | 200 lbf. |
| End Cap | No |
| Features | Mounted Cylindrical Cartridge Ball Bearing, Rubber Grommeted Wide Extended Inner Ring Bearing without Relubrication |
| Fixed Vs. Expansion | Fixed |
| Housing Color | Black |
| Housing Construction | One Piece |
| Housing Material | Rubber |
| Housing Style | Cartridge Block |
| Housing Type | Cartridge, Cylindrical |
| Housing Width | 1.01" |
| Htc | 8482.10.5048 |
| Includes | (2) Set Screws |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Ring Outside Diameter | 1.192" |
| Insert | RB-12 |
| Length Through Bore | 1 3/8" |
| Lubricant Material | NLGI #2 Equivalent |
| Lubrication Type | Lithium Complex NLGI 2 Grease |
| Max. Operating Temperature | 200°F |
| Maximum Speed | 7300 RPM |
| Maximum Temperature | 220°F |
| Minimum Temperature | -20°C |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Outer Ring Width | 1" |
| Outside Dia. | 4 1/2" |
| Outside Diameter | 2 17/32" |
| Overall Height | 4 1/2" |
| Overall Length | 4 1/2" |
| Overall Width | 1.38" |
| Radial Clearance | Standard |
| Ring Material | Alloy Steel |
| Ring Material Grade | Grade 52100 |
| Rolling Element | Ball Bearing |
| Rolling Element Rows | 1 |
| Seal Type | Felt Labyrinth Seal |
| Shaft Locking Type | Set Screw |
| Size Code | 2-012 |
| Static Load Rating | 1444 lbs. |
| Ship weight (kg) | 0.26 |
| Ship height (cm) | 3.96 |
| Ship length (cm) | 6.99 |
| Ship width (cm) | 6.99 |
| Country of Origin | MX |
