| Ability To Relubricate | Yes |
| Base Height | 1.25" |
| Base To Center Height | 2 1/4" |
| Base Width | 2.438" |
| Bearing Insert Finish | Uncoated |
| Bearing Insert Material | Alloy Steel |
| Bearing Insert Type | Tapered Roller |
| Bearing Material Grade | Grade 52100 |
| Bolt Center Max | 7.188" |
| Bolt Center Min | 6.313" |
| Bolt Center-to-center Length | 6 3/4" |
| Bolt Size | 5/8" |
| Bore Dia. | 1 3/4" |
| Bore Diameter | 1 3/4" |
| Bore Shape | Straight |
| Bore Type | Cylindrical |
| Centerline To Front Face | 1 3/4" |
| Closure | Double Sealed |
| Collar Outer Diameter | 3 1/4" |
| Duty/series | Standard |
| Dynamic Axial Load Capacity | 8070 lbf. |
| Dynamic Radial Load Capacity | 8070 lbs. |
| End Cap | No |
| Expansion | No |
| Expansion Type | Fixed |
| Features | Double-Collar Interlock with 120° Spacing Setscrew Lock, Diamond Faceted Setscrews, Heavy Duty Tapered Roller Bearings with Steel Cage for Radial, Thrust and Combined Loading, Powder Coat Epoxy 2-Bolt Split Cast Iron Housing, Race-Mounted Felt-Lined Flinger Seal |
| Foot Height | 1 1/4" |
| Grease Fitting Thread Size | 1/8" |
| Grease Fitting Thread Type | NPT |
| Housing Base | Solid |
| Housing Color | Gray |
| Housing Construction | Split Two Piece |
| Housing Material | Cast Iron |
| Housing Material Finish | Black Oxide |
| Housing Style | Pillow Block |
| Housing Type | Pillow Block, Two Bolt |
| Htc | 8483.20.8080 |
| Inner Race Heat Treat Method | Case Carburized Inner Ring |
| Inner Race Length | 3 1/2" |
| Insert Material | Steel |
| Insert Material Grade | 52100 |
| Insert Number | RCI-112 |
| Internal Clearance | Standard |
| Locking Type | Double Collar Mount |
| Lubricant Material | NGLI #2 Equivalent |
| Lubrication Type | Lithium, EP, NLGI#2 |
| Max. Operating Temperature | 220°F |
| Max. Speed | 2500 RPM |
| Maximum Misalignment Angle | 3° |
| Maximum Speed | 2500 RPM |
| Maximum Temperature | 220°F |
| Measure Units | Inch |
| Minimum Temperature | -20°F |
| Misalignment Capability | -3° to +3° |
| Misalignment Type | Static Only |
| Mount Hole Center-to-center Length | 7 3/16" |
| Mount Type | Bolt-Through |
| Mounting Bolt Size | 5/8" |
| Mounting Surface To Shaft Center Height | 2 1/4" |
| Number Of Mount Holes | 2 |
| Outer Ring Land Profile | Standard |
| Overall Height | 4 5/8" |
| Overall Length | 8 7/8" |
| Overall Width | 3 1/2" |
| Platform | RPB Series |
| Replaceable Insert | Yes |
| Retainer Material | Steel |
| Rolling Element | Tapered Roller |
| Seal Material | Felt |
| Seal Type | Felt Labyrinth Seal |
| Self Lubricating Bearing | Yes |
| Series | RPB |
| Shaft Locking Type | Set Screws |
| Split Housing | Split Horizontally |
| Static Radial Load Capacity | 2540 lbf. |
| Ship weight (kg) | 5.94 |
| Ship height (cm) | 14.94 |
| Ship length (cm) | 26.67 |
| Ship width (cm) | 10.49 |
| Country of Origin | US |
