| Ability To Relubricate | Yes |
| Bearing Insert Finish | Uncoated |
| Bore Dia. | 3 7/16" |
| Bore Shape | Straight |
| Collar Outer Diameter | 2 1/2" |
| Duty/series | Standard |
| End Cap | No |
| Fixed Vs. Expansion | No |
| Housing Type | Insert Only |
| Htc | 8482.20.0061 |
| Inner Race Heat Treat Method | Case Carburized Inner Ring |
| Inner Race Profile | Wide Inner Ring |
| Insert Material | Steel |
| Insert Material Grade | 52100 |
| Internal Clearance | Standard |
| Locking Type | Collar Mount |
| Lubrication Type | Lithium, EP, NLGI#2 |
| Max. Operating Temperature | 220°F |
| Max. Speed | 1500 RPM |
| Measure Units | Inch |
| Misalignment Capability | -3° to +3° |
| Misalignment Type | Static Only |
| Outer Race Od | 6.1" |
| Outer Race Profile | Spherical |
| Outer Race Width | 3" |
| Outer Ring Land Profile | Standard |
| Overall Width | 4.19" |
| Platform | RPB Series |
| Retainer Material | Steel |
| Rolling Element | Tapered Roller |
| Type Of Seal | Single Lip Contact Seal |
| Ship weight (kg) | 8.01 |
| Ship height (cm) | 20.96 |
| Ship length (cm) | 20.96 |
| Ship width (cm) | 18.11 |
| Country of Origin | US |
