| Ability To Relubricate | Yes |
| Adjusting Screw Clearance Hole Diameter | 1 22/25" |
| Adjusting Screw Square Nut Seat Height | 2 22/25" |
| Base To Center Height | 7.13" |
| Bearing Insert Finish | Black Oxide |
| Bearing Insert Material | Steel |
| Bearing Insert Material Grade | 52100 |
| Bearing Insert Type | Medium Duty |
| Bore Dia. | 3 15/16" |
| Bore Shape | Straight |
| Cage Material | Brass |
| Cage Type | Land Riding Retainer |
| Carriage Bolt Size | 1 1/2" |
| Centerline To Outermost Bearing Face | 2.683" |
| Dynamic Load Capacity | 29905 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | Fixed |
| Grease Fitting Thread Size | 1/8" |
| Grease Fitting Thread Type | NPT |
| Housing Coating | Powder Coated |
| Housing Color | Black |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Style | Take Up Block |
| Housing Type | Take Up Block, Wide Slot |
| Htc | 8483.20.4040 |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Ring Outside Diameter | 5.17" |
| Insert | 3-315C |
| Length Through Bore | 4.623" |
| Lubrication Type | Lithium Complex NLGI 2 Grease |
| Max. Operating Temperature | 220°F |
| Max. Speed | 1450 RPM |
| Misalignment Capability | -2° to +2° |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Height | 9.38" |
| Overall Length | 11 22/25" |
| Overall Width | 4.63" |
| Radial Clearance | Standard |
| Rolling Element | Ball Bearing |
| Seal Type | Single Lip Contact Seal |
| Series | MST |
| Shaft Locking Type | Set Screw |
| Size Code | 2-43 |
| Slot Length | 6 1/2" |
| Slot Spacing | 8 3/8" |
| Slot Width | 1.813" |
| Static Load Rating | 23553 lbs. |
| Vibration Frequency Fundamental Train | 0.0068 cPS |
| Vibration Frequency Inner Ring Defect | 0.0986 cPS |
| Vibration Frequency Outer Ring Defect | 0.0681 cPS |
| Vibration Frequency Roller Spin | 0.044 cPS |
