| Ability To Relubricate | Yes |
| Bearing Insert Finish | Black Oxide |
| Bearing Insert Material | Steel |
| Bearing Insert Material Grade | 52100 |
| Bearing Insert Type | Medium Duty |
| Bolt Circle | 6 1/2" |
| Bolt Size | 1/2" |
| Bore Dia. | 2 7/16" |
| Bore Shape | Straight |
| Cage Material | Brass |
| Cage Type | Land Riding Retainer |
| Dynamic Load Capacity | 13971 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | Fixed |
| Foot Height | 14/25" |
| Grease Fitting Thread Size | 1/8" |
| Grease Fitting Thread Type | NPT |
| Housing Coating | Powder Coated |
| Housing Color | Black |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Outside Diameter | 7.63" |
| Housing Style | Flange Block |
| Housing Type | Flange Cartridge |
| Htc | 8483.20.4040 |
| Inner Ring Outside Diameter | 3.438" |
| Length Through Bore | 2.748" |
| Lubrication Type | Goldplex FG |
| Max. Operating Temperature | 220°F |
| Max. Speed | 2250 RPM |
| Misalignment Capability | -2° to +2° |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Height | 2 21/25" |
| Overall Length | 7.63" |
| Overall Width | 7.63" |
| Pilot Configuration | Piloted |
| Pilot Depth | 1.094" |
| Pilot Diameter | 5 1/2" |
| Radial Clearance | Standard |
| Rolling Element | Ball Bearing |
| Seal Type | Single Lip Contact Seal |
| Series | CR Gold |
| Shaft Locking Type | Set Screw |
| Size Code | 2-211 |
| Static Load Rating | 10063 lbs. |
| Ship weight (kg) | 5.99 |
| Ship height (cm) | 20.17 |
| Ship length (cm) | 20.65 |
| Ship width (cm) | 8.89 |
| Country of Origin | US |
