| Axial Load | 2040 |
| Ball Diameter | 0.687" |
| Ball Finish | Chrome Plated |
| Ball Flat Diameter | 0.53" |
| Ball Material | Alloy Steel |
| Ball Width | 0.437" |
| Bore Dia. | 7/16" |
| Chamfer | 0.035" |
| Class | Commercial |
| Construction | Two Piece |
| Htc | 8483.30.8070 |
| Lubrication | Lubrication Hole No Zerk Fitting |
| Lubrication System | Thru OD |
| Lubrication Type | Grease |
| Max Static Radial Load | 10200 |
| Max. Ambient Temp. | 350°F |
| Misalignment Angle | -9.5° to +9.5° |
| Misalignment Angle B1 | -6.5° to +6.5° |
| Misalignment Angle B3 | 20.5° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Outside Dia. | 0.9062" |
| Product Type | COM |
| Race Material | Carbon Steel |
| Race Material Property | corrosion resistant coating |
| Race Width | 0.343" |
| Relubricatable | Yes |
| Seal Type | Unsealed |
| Series | COM |
| Type | Plain Spherical |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 6.86 |
| Ship length (cm) | 5.84 |
| Ship width (cm) | 1.78 |
| Country of Origin | MX |
