| Axial Load | 1290 |
| Ball Diameter | 0.562" |
| Ball Finish | Chrome Plated |
| Ball Flat Diameter | 0.419" |
| Ball Material | Alloy Steel |
| Ball Width | 3/8" |
| Bore Dia. | 5/16" |
| Chamfer | 0.025" |
| Class | Commercial |
| Construction | Two Piece |
| Htc | 8483.30.8070 |
| Lubrication | Lubrication Hole No Zerk Fitting |
| Lubrication System | Thru OD |
| Lubrication Type | Grease |
| Max Static Radial Load | 6450 |
| Max. Ambient Temp. | 350°F |
| Misalignment Angle | -12° to +12° |
| Misalignment Angle B1 | -8° to +8° |
| Misalignment Angle B3 | 26° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Outside Dia. | 3/4" |
| Product Type | COM |
| Race Material | Carbon Steel |
| Race Material Property | corrosion resistant coating |
| Race Width | 0.281" |
| Relubricatable | Yes |
| Seal Type | Unsealed |
| Series | COM |
| Type | Plain Spherical |
| Ship weight (kg) | 0.01 |
| Ship height (cm) | 6.22 |
| Ship length (cm) | 5.21 |
| Ship width (cm) | 1.14 |
| Country of Origin | MX |
