| Axial Load | 10940 |
| Ball Diameter | 1 1/2" |
| Ball Finish | Chrome Plated |
| Ball Flat Diameter | 1.118" |
| Ball Material | Alloy Steel |
| Ball Width | 1" |
| Bore Dia. | 1" |
| Chamfer | 0.045" |
| Class | Commercial |
| Construction | Two Piece |
| Htc | 8483.30.8070 |
| Lubrication | Lubrication Hole No Zerk Fitting |
| Lubrication System | Thru OD |
| Lubrication Type | Grease |
| Max Static Radial Load | 54700 |
| Max. Ambient Temp. | 350°F |
| Misalignment Angle | -9.5° to +9.5° |
| Misalignment Angle B1 | -7° to +7° |
| Misalignment Angle B3 | 16° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Outside Dia. | 1 3/4" |
| Product Type | COM |
| Race Material | Carbon Steel |
| Race Material Property | corrosion resistant coating |
| Race Width | 0.797" |
| Relubricatable | Yes |
| Seal Type | Unsealed |
| Series | COM |
| Type | Plain Spherical |
| Ship weight (kg) | 0.17 |
| Ship height (cm) | 5.21 |
| Ship length (cm) | 6.22 |
| Ship width (cm) | 2.92 |
| Country of Origin | MX |
