| Ability To Relubricate | No |
| Across Wrench Flats | 0.562" |
| Axial Load | 295 |
| Ball Diameter | 0.718" |
| Ball Finish | Chrome Plated |
| Ball Flat Diameter | 0.517" |
| Ball Material | Alloy Steel |
| Ball Width | 1/2" |
| Base Diameter | 0.688" |
| Bearing Insert Type | Rod End |
| Bore Dia. | 3/8" |
| Class | Precision |
| Configuration | Female |
| Construction | Two Piece Rod End |
| Head Diameter | 1" |
| Housing Style | Female Rod End |
| Housing Width | 0.406" |
| Htc | 8483.30.8055 |
| Length To Center Of Ball | 1.63" |
| Liner | TEFLON Fabric Liner |
| Lubrication | No Zerk Fitting |
| Lubrication Method | Self Lubricating |
| Lubrication Type | Self Lubricating |
| Max Static Radial Load | 2950 |
| Max. Ambient Temp. | 250°F |
| Misalignment Angle | -6° to +6° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Product Selection Available Sw | Yes |
| Product Type | CFF |
| Race Material | TEFLON |
| Series | Precision |
| Thread Direction | LH |
| Thread Length | 0.781" |
| Thread Size | 3/8"-24 |
| Thread Type | UNF |
| Type | Female Rod End |
| Zerk Fitting Sw | No |
| Ship weight (kg) | 0.25 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 5.41 |
| Ship width (cm) | 1.42 |
| Country of Origin | MX |
