| Item | Controller |
| Amps | 2A |
| Depth | 2.43" |
| Discrete Input Number | 22 , 6 |
| Height | 4.33" |
| Input Voltage | 12-24V |
| Output Type | Analog, Relay |
| Port Type | 1 Lan Expansion Bus, 1 RS485 |
| Slots | 1 Lan Expansion Bus, 1 RS485 - Screw Terminal Block Modbus Serial Link |
| Timers | Programmable |
| Width | 5.51" |
| Ac Voltage Rating | 12-24V AC |
| Analog Output | 0-10V DC |
| Clock Included | Clock Included |
| Communication Protocol | Modbus |
| Current | 2A |
| Dc Voltage Rating | 24V DC |
| Display Qty | 1 |
| Display Type | LED |
| Features | Volt Free Contacts |
| Input Circuit Current - Maximum | 20 mA |
| Input Circuit Current - Minimum | 4 mA |
| Input Circuit Voltage - Maximum | 10V |
| Input Circuit Voltage - Minimum | 0V |
| Mounting Style | Surface |
| Number And Type Of Inputs | (5) Analog,(6) Digital |
| Number And Type Of Outputs | (5) Analog,(6) Digital |
| Number Of Inputs | 11 |
| Number Of Outputs | 11 |
| Output Circuit Current - Maximum | 2A |
| Output Circuit Voltage - Maximum | 10V |
| Output Circuit Voltage - Minimum | 0V |
| Overall Depth | 2.43" |
| Overall Height | 4.33" |
| Overall Width | 5.51" |
| Product Type | Programmable Logic Controller |
| Series | M171 Series |
| Supply Voltage Rating | 12-24V AC/24V DC |
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 11 |
| Ship length (cm) | 6.17 |
| Ship width (cm) | 14 |
| Country of Origin | IT |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
TM171ODM14R | Controller | €264.48 | |
 |
TM171OD14R | Controller | €241.60 | |
 |
TM171OD22R | Controller | €272.62 | |
 |
TM171ODM22S | Controller | €431.85 | |
 |
TM171ODM22R | Controller | €273.91 | |
 |
TM171OBM14R | Controller | €252.67 | |
 |
TM171OBM22R | Controller | €225.70 |
