| Item | Voltage Sensing Relay |
| Ac Contact Rating | 5A @ 120/240V |
| Base Shape | Square |
| Body Depth | 2 21/25" |
| Body Height | 3.54" |
| Body Width | 1.38" |
| Body Width - Relay | 1.38" |
| Contact Form | DPDT |
| Current Rating | 5A |
| Dc Contact Rating | 5A @ 250V |
| Electrical Connection Type | Screw |
| Electrical Operating Durability | 100000 |
| Flat Pin Width | Not Applicable |
| Frequency | 50/60 Hz |
| Housing Material | Plastic |
| Input Voltage | 120-277V AC |
| Max. Switching Amps | 5A |
| Max. Switching Capacity | 1250 VA |
| Max. Switching Current | 5A |
| Mechanical Operating Durability | 30000000 |
| Min. Switching Amps | 10 mA |
| Min. Switching Current | 10 mA |
| Monitored Parameters | Absence Of Neutral, Over, Under Voltage , Absence Of Neutral, Overvoltage, Undervoltage |
| Nominal Output Amps | 5A |
| Non-dissipating Shock Wave | 4 kV |
| Number Of Pins | 12 |
| Number Of Pins - Relay | 6 |
| Number Of Pins/terminals | 12 |
| Operating Position | Any Position Without Derating |
| Overall Depth | 2 21/25" |
| Overall Height - Relay | 3.65" |
| Power Consumption | 1250 VA |
| Product Type | Voltage Control Relay |
| Relay Mounting Style | Din Rail |
| Relay Type | Voltage Control Relay |
| Restart | Auto |
| Restart Time Delay | 1.5 sec. |
| Run-up Delay At Power-up | 650 ms |
| Switching Capacity In Va | 1250 VA |
| Voltage Detection Threshold | 114V |
| Width | 35 mm |
| Contact Rating (ac) | 5A @ 120/240V |
| Contact Rating (dc) | 5A @ 250V |
| Maximum Switching Capacity | 1250 VA |
| Maximum Switching Current | 5A |
| Minimum Switching Current | 10 mA |
| Standards | C-TICK, CSA CERTIFIED, EN/IEC 60255-1, EN/IEC 61000-6-4, EU ROHS, GL, GOST, REACH REGULATION, UL LISTED |
| Ship weight (kg) | 0.12 |
| Ship height (cm) | 8.99 |
| Ship length (cm) | 7.21 |
| Ship width (cm) | 3.51 |
| Country of Origin | ID |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
RM22TU21 | Phase Monitor Relay | €268.33 | |
 |
RM17TT00 | Relay | €233.40 | |
 |
RM35TM250MW | Current Sensing Relay | €324.36 | |
 |
RM22TG20 | Relay | €110.15 | |
 |
RM22TR33 | Relay | €191.59 | |
 |
RM35BA10 | Relay | €421.45 | |
 |
RM35ATW5MW | Relay | - | RFQ
|
