| Item | Lever |
| Ada Compliant | No |
| Cylinder Core Type | Not Included |
| Electrical/mechanical | Mechanical |
| Features | Cylindrical Locks |
| Finish | Satin Chrome |
| Fire Rated | Not Rated |
| For Use With | Various Door Types |
| Function | Passage |
| Handle Material | Brass |
| Handle Type | Lever |
| Includes | Strike |
| Key Type | Not Keyed |
| Keying | Unkeyed |
| Keyway Type | None |
| Ligature Resistant | No |
| Location Type | Commercial |
| Lockset Fire Rating | Not Rated |
| Lockset Performance Strength | Medium Duty |
| Mortise / Cylindrical | Cylindrical |
| Number Of Keys | 0 |
| Pins | 0 |
| Required Door Thickness | 1 3/8" to 2" |
| Strike Dim. | 1 1/4" x 4 7/8" |
| Style | S Jupiter |
| Visual Indicator Message | No Message |
| Ansi Grade | Grade 2 |
| Ansi Lockset Function | Passage |
| Backset | 2 3/8" |
| Bolt Type | Dead Latch |
| Door Thickness - Maximum | 1 7/8" |
| Door Thickness - Minimum | 1 3/8" |
| Fire Rating | 3 hrs. |
| General Lockset Function | Passage Lever Locksets |
| Hand Orientation | Non Handed |
| Includes Core | Core Not Included |
| Inside Locking Access | Not Lockable |
| Knob/handle Material | Brass |
| Ligature Resistance | Not Ligature Resistant |
| Lock Assembly Type | Cylindrical |
| Lockset Function Ansi Code | F75 |
| Lockset Handle Type | Lever |
| Lockset Style | S Jupiter |
| Lockset Type | Mechanical |
| Number Of Pins | 0 |
| Outside Locking Access | Not Lockable |
| Performance Duty Rating | 2 |
| Standards | ANSI/BHMA A156.2-2017, BAA, ICC A117.1, UL LISTED |
| Strike Plate Height | 2 3/4" |
| Strike Plate Lip Length | 1 1/8" |
| Strike Plate Width | 1 1/8" |
| Strike Type | T-Strike |
| Ul Fire Rating | UL10C |
| Ship weight (kg) | 1.17 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
09-138 SL1 630 P | Antiligature Lever | €2,322.89 | |
 |
09-138 SL1 630 BD | Antiligature Lever | €2,123.48 | |
|
L9465P SL1 630 | Door Lever Lockset | €2,531.72 | |
|
L9080J SL1 630 | Door Lever Lockset | €2,408.55 | |
 |
L9010 SL1 630 | Door Lever Lockset | €2,217.32 | |
|
L9070J SL1 630 | Door Lever Lockset | €2,439.16 | |
|
L9465BD SL1 630 | Door Lever Lockset | €2,515.75 |
