| Item | Lever |
| Ada Compliant | Yes |
| Ansi Grade | Grade 2 |
| Ansi Lockset Function | Storeroom |
| Backset | 2 3/4" |
| Bolt Type | Dead Latch |
| Cylinder Core Type | Small Format Interchangeable Core Cylinder |
| Door Thickness - Maximum | 1 3/4" |
| Door Thickness - Minimum | 1 3/8" |
| Features | Deep-Drawn Spindle With 5 Points Of Lever Engagement Minimizes Droop And Wobble, Suites Perfectly With Nd Series Grade 1 Cylindrical And Nd Series Electrified Cylindrical |
| Finish | Satin Chromium Plated |
| Fire Rating | 3 hrs. |
| General Lockset Function | Storeroom Lever Locksets |
| Hand Orientation | Non Handed |
| Includes Core | Core Included |
| Key Type | Not Keyed |
| Keyway Type | Less Cylinder |
| Knob/handle Material | Steel |
| Ligature Resistance | Not Ligature Resistant |
| Lock Assembly Type | Cylindrical |
| Lockset Function Ansi Code | F86 |
| Lockset Handle Type | Lever |
| Lockset Style | ALX Athens |
| Lockset Type | Mechanical |
| Number Of Keys | 0 |
| Number Of Pins | 6 |
| Outside Locking Access | Keyway |
| Performance Duty Rating | 2 |
| Properties | Corrosion Resistant |
| Standards | ANSI A156.2-2017, BAA/TAA, CALIFORNIA FIRE CODE, CAN/ULC S104, COMPLIES WITH ICC A117.1-2017 ACCESSIBLE AND USABLE BUILDINGS AND FACILITIES, FF-H-106C SERIES 161, FLORIDA BUILDING COMMISSION (ASTM E330, E1886, E1996), TDI (ASTM E330, E1886, E1996), UL 437 |
| Strike Plate Height | 4 7/8" |
| Strike Plate Lip Length | 1 3/16" |
| Strike Plate Width | 1 1/4" |
| Strike Type | Curved Lip |
| Ul Fire Rating | UL10C |
| Visual Indicator Location | Inside/Outside |
| Visual Indicator Message | No Message |
| Ship weight (kg) | 1.8 |
| Country of Origin | MX |
| Product | Model | Price | |
|---|---|---|---|
 |
ALX10 ATH 613 | €317.93 | |
 |
ALX10 ATH 626 | €282.94 | |
 |
ALX10 SPA 626 | €255.89 | |
 |
ALX10 SAT 613 | €291.14 | |
 |
ALX10 SAT 626 | €242.82 | |
 |
ALX40 ATH 613 | €353.97 | |
 |
ALX40 ATH 626 | €344.68 |
