| Geometry | Cylindrical |
| Height (h1) | 2.17 in (55 mm) |
| Max Axial Load | 1688.32 lb (7510 N) |
| Max Deflection | 0.54 in (13.7 mm) |
| Metal Material | Zinc Plated Steel |
| Metallic Body Finish | Zinc-Plated |
| Outer Diameter (od) | 2.95 in (75 mm) |
| Plate Thickness (pt) | 0.12 in (3 mm) |
| Rubber Material | Natural Rubber |
| Shore Hardness | 55A (+/- 5) |
| Spring Rate | 3112.03 lb/in (545 N/mm) |
| Stud Length (ls) | 1.46 in (37 mm) |
| Tapped Hole Depth (lt) | 0.47 in (11.9 mm) |
| Thread (th) | M12 x 1.75 |
| Ship weight (kg) | 0.45 |
| Ship height (cm) | 5.51 |
| Ship length (cm) | 7.49 |
| Ship width (cm) | 7.49 |
| Country of Origin | HU |
