| Item | Shaft Collar |
| Bore Dia. | 2.437" |
| Clearance Dia. | 3.707" |
| Collar Style | Clamp |
| Dimension Type | Standard |
| Grade | Grade 303 |
| Material | Stainless Steel |
| Number Of Pieces | 2 |
| Operating Temp. Range | -40°F to +350°F |
| Outside Dia. | 3 1/2" |
| Screw Material | Stainless Steel |
| Width | 3/4" |
| Bore Diameter | 2 7/16" |
| Bore Tolerance | +0.002/+0.0005" |
| Bore Type | Round Keyed |
| Clearance Diameter | 3.71" |
| Collar Construction | 2-Piece |
| Collar Material | Stainless Steel |
| Collar Material Finish | Bright |
| Collar Material Grade | 303 |
| Collar Outside Diameter | 3 1/2" |
| Collar Width | 3/4" |
| For Shaft Diameter | 2 7/16" |
| Included Screws | (2) Hex Socket Cap Screw |
| Keyway Depth | 5/16" |
| Keyway Width | 5/8" |
| Maximum Operating Temperature | 350°F |
| Minimum Operating Temperature | -40°F |
| Resistance Properties | Corrosion Resistant |
| Screw Location From Center | 1.48" |
| Screw Material Finish | Bright |
| Screw Material Grade | Grade 304 |
| Screw Seating Torque | 190 lbs.-in. |
| Screw Thread Size | 5/16"-24 |
| Shaft Locking Type | Clamp On |
| Shaft Tolerance | +0/-0.0005" |
| Standards | ANSI, CONFLICT MINERALS COMPLIANT, ISO 9001:2015, REACH COMPLIANT, ROHS COMPLIANT |
| System Of Measurement | Imperial |
| Width Tolerance | +0.003/-0.01" |
| Ship weight (kg) | 0.42 |
| Ship height (cm) | 2.03 |
| Ship length (cm) | 15.24 |
| Ship width (cm) | 1.91 |
| HS code | 8483608000 |
| Country of Origin | US |
| Product | Model | Bore Dia. | Clearance Dia. | Material | Operating Temp. Range | Outside Dia. | Screw Material | Screw Size | Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SPK-10-A | 5/8" | 1.5" | 2024 Aluminum | -40 Degrees to 225 Degrees F | 1 5/16" | Alloy Steel | #10-32 | 7/16" | €42.13 | |
 |
SPK-10-F | 5/8" | 1.5" | Black Oxide 1215 Lead Free Steel | -40 Degrees to 350 Degrees F | 1 5/16" | Alloy Steel | #10-32 | 7/16" | €37.62 | |
|
SPK-10-SS | 5/8" | 1.5" | 303 Stainless Steel | -40 Degrees to 350 Degrees F | 1 5/16" | Stainless Steel | #10-32 | 7/16" | €70.43 | |
|
SPK-12-A | 3/4" | 1.808" | 2024 Aluminum | -40 Degrees to 225 Degrees F | 1.5" | Alloy Steel | 1/4"-28 | 1/2" | €43.91 | |
|
SPK-12-F | 3/4" | 1.808" | Black Oxide 1215 Lead Free Steel | -40 Degrees to 350 Degrees F | 1.5" | Alloy Steel | 1/4"-28 | 1/2" | €40.21 | |
|
SPK-12-SS | 3/4" | 1.808" | 303 Stainless Steel | -40 Degrees to 350 Degrees F | 1.5" | Stainless Steel | 1/4"-28 | 1/2" | €74.16 | |
|
SPK-16-A | 1" | 2.032" | 2024 Aluminum | -40 Degrees to 225 Degrees F | 1.75" | Alloy Steel | 1/4"-28 | 1/2" | €47.95 |
