| Item | Rigid Shaft Coupling |
| Bore Dia. | 5/8" |
| Clearance Dia. | 1.313" |
| Finish | Black Oxide |
| Keyway Width | 0.188" |
| Material | Steel |
| Max. Rpm | 4000 RPM |
| Max. Torque | 475 lbs.-in. |
| Outside Dia. | 1.312" |
| Overall Length | 2" |
| Type | One Piece Set Screw |
| Bore Diameter 1 | 5/8" |
| Bore Diameter 2 | 5/8" |
| Bore Tolerance | +0.0020"/+0.0005" |
| Bore Type | Round Keyed |
| Clearance Diameter | 1.31" |
| Coupling Construction | One-Piece |
| Coupling Material | Carbon Steel |
| Coupling Material Finish | Black Oxide |
| Coupling Material Grade | Grade 1215 |
| Coupling Outside Diameter | 1 5/16" |
| Different Bore Sizes | No |
| Fastener Tightening Torque | 165 lbs.-in |
| Features | Precision Honed Bores, Vibration Resistant Screws |
| Included Screws | (4) Set Screws |
| Keyway Depth 1 | 3/32" |
| Keyway Depth 2 | 3/32" |
| Keyway Width 1 | 3/16" |
| Keyway Width 2 | 3/16" |
| Maximum Bore Diameter | 5/8" |
| Maximum Operating Temperature | 350°F |
| Maximum Speed | 4000 RPM |
| Minimum Operating Temperature | -40°F |
| Number Of Locking Screws | 4 |
| Rated Torque | 1600 lbs.-in. |
| Resistance Properties | Corrosion Resistant |
| Screw Material | Alloy Steel |
| Screw Material Finish | Black Oxide |
| Screw Thread Size | 5/16"-18 |
| Shaft Locking Type | Set Screw |
| Shaft Tolerance | +0"/-0.0005" |
| Standards | ANSI, CONFLICT MINERALS COMPLIANT, REACH COMPLIANT, ROHS3 COMPLIANT |
| System Of Measurement | Imperial |
| Zero Backlash | Yes |
| Ship weight (kg) | 0.26 |
| Ship height (cm) | 3.81 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 3.81 |
| HS code | 8483608000 |
| Country of Origin | US |
| Model | Bore Dia. | Clearance Dia. | Keyway Width | Material | Max. Torque | Outside Dia. | Overall Length | Screw Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| SCC-22-22-F | 1.375" | 2.5" | 5/16" | Black Oxide Steel | 1450 In.Lbs. | 2.5" | 3.625" | 3/8-16" | €171.39 | |
| SCC-24-24-F | 1.5" | 2.625" | 3/8" | Black Oxide Steel | 1600 In.Lbs. | 2.625" | 3.875" | 3/8-16" | €193.67 | |
| SCC-8-8-F | 1/2" | 1.125" | 1/8" | Black Oxide Steel | 240 In.Lbs. | 1.125" | 1.75" | 1/4-20" | €73.34 | |
| SCC-12-12-F | 3/4" | 1.5" | 3/16" | Black Oxide Steel | 600 In.Lbs. | 1.5" | 2.25" | 5/16-18" | €95.35 | |
| SCC-14-14-F | 7/8" | 1.625" | 3/16" | Black Oxide Steel | 675 In.Lbs. | 1.625" | 2.5" | 5/16-18" | €106.87 | |
| SCC-16-16-F | 1" | 1.75" | 1/4" | Black Oxide Steel | 750 In.Lbs. | 1.75" | 3" | 5/16-18" | €101.85 | |
| SCC-18-18-F | 1.125" | 1.875" | 1/4" | Black Oxide Steel | 1200 In.Lbs. | 1.875" | 3.125" | 3/8-16" | €125.58 |
