| B1 Max Shaft Penetration | 11.0 mm |
| B2 Max Shaft Penetration | 11.0 mm |
| Balanced Design | Yes |
| Bore (b1) | 4 mm |
| Bore Tolerance | +0.050 mm / +0.012 mm |
| Clearance Diameter (c) Max | 15.0 mm |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | M2 |
| Full Bearing Support Required? | No |
| Hex Wrench Size | 1.5 mm |
| Length (l) | 22 mm |
| Material Specification | Type 303 Austenitic, Non-Magnetic Bar |
| Maximum Speed | 4,000 RPM |
| Moment Of Inertia | 7.029 x 10 |
| Number Of Screws | 8 ea |
| Outer Diameter (od) | 15 mm |
| Precision Honed Bores? | Yes |
| Rated Torque | 1.99 Nm |
| Recommended Gap | 0.79 mm |
| Recommended Shaft Tolerance | +0.000 mm / -0.013 mm |
| Screw Finish | Bright |
| Screw Location (r) | 4.6 mm |
| Screw Material | 18-8 300 Series Stainless Steel |
| Seating Torque | 0.36 Nm |
| Small Bore (b2) | 4 mm |
| Temperature | -40°F to 350°F (-40°C to 176°C) |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 1.5 |
| Ship length (cm) | 2.2 |
| Ship width (cm) | 1.5 |
| Country of Origin | US |
