| Angular Misalignment | 1.5° |
| Axial Motion | 1.00 mm |
| B1 Max Shaft Penetration | 22.4 mm |
| Balanced Design | Yes |
| Bore (b1) | 11 mm |
| Bore Tolerance | +0.06 mm / +0.02 mm |
| Finish | Clear Anodized |
| Finish Specification | Clear Anodized |
| Forged Clamp Screw | M6 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 5.0 mm |
| Hub Width (lh) | 15.00 mm |
| Length (l) | 1.772 in (45.0 mm) |
| Material Specification | 6082 Aluminum Bar |
| Maximum Speed | 10,000 RPM |
| Number Of Screws | 1 ea |
| Outer Diameter (od) | 2.205 in (56.0 mm) |
| Parallel Misalignment | 1.50 mm |
| Peak Torque | 10 Nm |
| Rated Torque | 7 Nm |
| Recommended Inserts | CPFRG35/56-AT |
| Screw Finish | Black Oxide |
| Screw Location (r) | 19.3 mm |
| Screw Material | Alloy Steel |
| Seating Torque | 8.0 Nm |
| Space Between Hubs (ls) | 0.590 in (15.0 mm) |
| Temperature | -22°F to 175°F (-30°C to 80°C) |
| Torsional Stiffness | 7.20 Nm/Deg |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 5.6 |
| Ship length (cm) | 4.5 |
| Ship width (cm) | 5.6 |
| Country of Origin | DE |
