| 20 | $23.90 |
| 200 | Request Quote |
| Angular Misalignment | 1.0° |
| Axial Motion | 0.30 mm |
| B1 Max Shaft Penetration | 5.6 mm |
| Balanced Design | Yes |
| Bore (b1) | 9 mm |
| Bore Tolerance | +0.05 mm / +0.01 mm |
| Finish | Clear Anodized |
| Finish Specification | Clear Anodized |
| Forged Clamp Screw | #2-56 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 5/64 in |
| Hub Width (lh) | 5.64 mm |
| Length (l) | 0.787 in (20.0 mm) |
| Material Specification | 6082 Aluminum Bar |
| Maximum Speed | 25,000 RPM |
| Number Of Screws | 1 ea |
| Outer Diameter (od) | 0.748 in (19.0 mm) |
| Parallel Misalignment | 0.40 mm |
| Peak Torque | 1.4 Nm |
| Rated Torque | 0.6 Nm |
| Recommended Inserts | CPFRG12/19-AT |
| Screw Finish | Black Oxide |
| Screw Location (r) | 6.4 mm |
| Screw Material | Alloy Steel |
| Seating Torque | 0.4 Nm |
| Space Between Hubs (ls) | 0.347 in (8.8 mm) |
| Temperature | -22°F to 175°F (-30°C to 80°C) |
| Torsional Stiffness | 0.56 Nm/Deg |
| Zero-backlash? | Yes |
| Ship height (cm) | 1.9 |
| Ship length (cm) | 2 |
| Ship width (cm) | 1.9 |
| Country of Origin | DE |
