| Angular Misalignment | 1.0° |
| Axial Motion | 0.010 in |
| B1 Max Shaft Penetration | 0.755 in |
| B2 Max Shaft Penetration | 0.755 in |
| Balanced Design | Yes |
| Bore (b1) | 0.6250 in |
| Bore Tolerance | +0.001 in / -0.000 in |
| Dynamic Torque Non-reversing | 90 lb-in |
| Dynamic Torque Reversing | 45 lb-in |
| Finish Specification | Sulfuric Anodized MIL-A-8625 Type II, Class 2 and ASTM B580 Type B Black Anodize |
| Forged Clamp Screw | M4 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 3.0 mm |
| Hub Width (lh) | 0.710 in |
| Length (l) | 1.563 in |
| Material Specification | Hubs: 2024-T351 Aluminum Bar, Disc Springs: Type 302 Stainless Steel |
| Maximum Speed | 10,000 RPM |
| Moment Of Inertia | 0.0961 lb-in |
| Number Of Screws | 2 ea |
| Outer Diameter (od) | 1.625 in |
| Parallel Misalignment | 0.00 in |
| Recommended Hex Key | Metric Hex Keys |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Seating Torque | 4.6 Nm |
| Small Bore (b2) | 0.5000 in |
| Static Torque | 180 lb-in |
| Temperature | -40°F to 200°F (-40°C to 93°C) |
| Torque Wrench | TW:BT-1R-1/4-41.0 |
| Torsional Stiffness | 625 lb-in/Deg |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.12 |
| Ship height (cm) | 4.13 |
| Ship length (cm) | 3.97 |
| Ship width (cm) | 4.13 |
| Country of Origin | US |
