| Cooling Capacity | 17060 btuH |
| Depth | 9" |
| Height | 55" |
| Housing Material | Carbon Steel |
| Mounting | Wall Mount |
| Width | 18" |
| Control Type | Basic Controller |
| Cooling Capacity - Maximum | 17061 btuH |
| Cooling Method | Air, Water |
| Cooling Setpoint - Maximum | 131°F |
| Cooling Setpoint - Minimum | 68°F |
| Current | 1.45/1.45A |
| Environment | Indoor Dust Tight |
| Frequency | 50/60 Hz |
| Housing Color | Slate Gray |
| Includes | Drilling Template, Sealing and Assembly Parts |
| Mounting Type | Wall Mount |
| Nema Enclosure Rating | 12 |
| Operating Temperature - Maximum | 158°F |
| Operating Temperature - Minimum | 34°F |
| Operating Voltage | 230V |
| Operation Mode | Cooling Only |
| Overall Depth | 8.66" |
| Overall Height | 55.12" |
| Overall Width | 17.72" |
| Phase | Single |
| Power Consumption | 5 kW |
| Product Type | Heat Exchanger |
| Standards | CSA, CUL, CUR, FTTA, UL, UR |
| Wiring Method | Fully Wired |
| Ship weight (kg) | 40.5 |
| Ship height (cm) | 139.7 |
| Ship length (cm) | 22.86 |
| Ship width (cm) | 45.72 |
| Country of Origin | DE |
