| Item | Valve |
| Application | Chemical Metering |
| Body Grade | Grade 316 |
| Body Material | Stainless Steel |
| Function | Relieves Pressure |
| Height | 4 1/4" |
| Includes | Valve |
| Inlet Port Size | 1/2" |
| Inlet Port Type | FNPT |
| Max. Flow Rate | 15 GPM |
| Max. Fluid Temp. | 300°F |
| Max. Pressure | 150 psi |
| Outlet Port Size | 1/2" |
| Outlet Port Type | FNPT |
| Pressure Range | 10 psi to 150 psi |
| Type | Pressure Relief |
| Connection Type | NPT x NPT |
| Factory Set Pressure | 50 psi |
| For Media | Corrosive Liquids, Non-Flammable Liquids, Non-Potable Water, Potable Water |
| Inlet Connection Size | 1/2" |
| Max. Continuous Flow Rate | 15 GPM |
| Max. Intermittent Flow Rate | 1.7 GPM |
| Max. Operating Temperature | 300°F |
| Nsf Certifications | NSF 51, NSF 61 |
| Operating Pressure Range | 10 psi to 150 psi |
| Outlet Connection Size | 1/2" |
| Overall Height | 4 1/4" |
| Overall Width | 2 3/8" |
| Port Design | Full Port |
| Pressure Adjustment Range | 10 psi to 150 psi |
| Ship weight (kg) | 1.21 |
| Ship height (cm) | 11.68 |
| Ship length (cm) | 16 |
| Ship width (cm) | 11.18 |
| HS code | 8481400000 |
| Country of Origin | US |
