| Item | Mortiser |
| Base Size | 14" x 16" |
| Chuck Size | 1/2" |
| Fence Size | 4 1/2" x 20 1/4" |
| Hp | 1 hp |
| Includes | 4 In Chuck Key, Stand |
| Kit Contents | Bare Tool |
| Operation | Manual |
| Phase | 1 |
| Power Source | Corded |
| Spindle Speed | 1725 RPM |
| Table Work Surface | 7" x 20 1/4" |
| Travel | 4" |
| Travel Length | 4" |
| Voltage | 115/230V |
| Base Length | 16" |
| Base Width | 14" |
| Chisel Capacity | 1" |
| Chisel Center To Fence | 4" |
| Chisel Shank Diameter | 5/8", 3/4", 1-1/8" |
| Chisel Stroke | 10 3/4" |
| Compatible Bushing Size | 5/8", 3/4", 1 1/8" |
| Cross Table Travel | 4" |
| Current | 5.5/11A |
| Fence Height | 20 1/4" |
| Fence Length | 4 1/2" |
| Head Stroke | 6" |
| Horsepower | 1 hp |
| Longitudinal Travel | 15 1/2" |
| Overall Depth | 21 1/4" |
| Overall Height | 74" |
| Overall Width | 21 5/8" |
| Table Length | 20 1/4" |
| Table Tilt Angle | 35° |
| Table Width | 7" |
| Tool Weight | 292 lbs. |
| Ship weight (kg) | 131.4 |
| Ship height (cm) | 187.96 |
| Ship length (cm) | 53.98 |
| Ship width (cm) | 54.93 |
| HS code | 8465930090 |
| Country of Origin | TW |
