| Bearing Type | Plain |
| Bolt Size | 1/4" |
| Dimension B | 4 3/4" |
| Dimension C | 4" |
| Dimension E | 4 1/8" |
| Dimension G | 3 1/2" |
| Dimension J | 1/2" |
| Dimension K | 2 7/8" |
| Dimension M | 3" |
| Dimension P (in.) | 2 1/2" |
| Flange Width | 4 3/4" |
| Housing Style | Single |
| Inside Dia. | 1 1/2" |
| Length | 4" |
| Lock Type | Retaining Ring |
| Lubrication | No Lubrication System |
| Mounting Surface To Shaft Center (in.) | 1 3/4" |
| Pillow Block Type | Closed |
| Retaining Ring | External |
| System Of Measurement | Inch |
| Type | Closed Pillow Block |
| Accelerated Speed | 14 FPS |
| Body Width | 3.5" |
| Dynamic Load Capacity | 14100 lbf. |
| Flange Thickness | 1/2" |
| Inside Diameter | 1 1/2" |
| Liner | Frelon Gold |
| Locking Type | Retaining Ring |
| Material | Aluminum Alloy |
| Maximum Operating Temperature | 400°F |
| Minimum Operating Temperature | -400°F |
| Mounting Hole Diameter | 0.281" |
| Mounting Surface To Shaft Center | 1 3/4" |
| Overall Height | 3 1/4" |
| Overall Length | 4" |
| Self-alignment | Self-Aligning |
| Static Load Capacity | 14100 lbf. |
| Steady State Speed | 5 FPS |
| Ship weight (kg) | 1.53 |
| Ship height (cm) | 8.26 |
| Ship length (cm) | 10.16 |
| Country of Origin | US |
